Item |
ID(inner diameter) (mm) |
Tolerance of ID (mm) |
Wall thickness (mm) |
Tolerance of wall thickness (mm) |
Length (mm) |
SFG-1 |
0.5, 0.6, 0.7, 0.8, 0.9, 1.0 |
±0.05 |
0.2 |
±0.05 |
≥200 |
0.3 |
|||||
1.2, 1.4, 1.5, 1.6, 1.8 |
±0.08 |
0.2 |
±0.05 |
||
0.3 |
|||||
0.4 |
±0.08 |
||||
2, 2.2, 2.4, 2.5, 2.6, 2.8, 3.0, 3.2, 3.4, 3.5, 3.6, 3.8, 4.0 |
±0.10 |
0.2 |
±0.05 |
||
0.3 |
|||||
0.4 |
±0.08 |
||||
0.5 |
±0.10 |
||||
1.0 |
±0.15 |
||||
SFG-2 |
5, 6, 7, 8 |
±0.10 |
0.5 |
±0.08 |
According to the customer's demand |
1.0 |
±0.10 |
||||
1.5 |
|||||
2.0 |
|||||
9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 25 |
±0.10~±0.20 |
1.0 |
±0.10~±0.15 |
≥200 |
|
1.5 |
|||||
2.0 |
|||||
≥25 |
±0.25 |
1.5~2.0 |
±0.20 |
Note: The information above is just for your reference. The final products depend on the customer's technical requirements.
