Dark Red Heat Resistant Silicone Rubber Sheet Reinforced with 1PLY Fabric
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ROHS/FCC/SGS |
| Model Number | 3A1001 |
| Minimum Order Quantity | 10rolls |
| Price | USD3-15.00/kg |
| Packaging Details | packing in rolls, bags and pallets |
| Delivery Time | 7-15days after receive the buyer's payment |
| Payment Terms | T/T,L/C,Paypal,Western Union,D/P,Alipay,Wechat |
| Supply Ability | 100000kgs per month |
Product Details
| Material | Silicone+PLY+silicone | PLY Material | Aramid Fabric Or Glassfiber Fabric |
|---|---|---|---|
| Color | Dark Red Color | Tensile Strength | 7-12Mpa |
| Hardness | 40-80 Shore A | Elongation | 100% |
| Thickness | 0.5-6.0mm | Width | 0.5-3.6m |
| Length | 10-20m | Packing | In Crates |
| Flammability | UL94-V0 | Customization | Size, Color, Printing |
| Tempearture | -60~230℃ | Port | Shanghai Port And Others |
| Adhesive Backing | Yes, Custom | Surface | Double Impression Fabric |
| Heater Width | As Per The Buyer's Request | Backing Adhesive | Agreed |
| Feature | High Temperature Resistance | Others | As Per Buyer's Drawing |
| Flameresistance | UL94V-0 | ||
| Highlight | silicone gasket sheet,flexible rubber sheet |
||
Product Description
Dark Red Heat Resistant Silicone Rubber Sheet Rolls Reinforced To Insert 1PLY Fabric
Product Overview
Dark red heat resistant silicone rubber sheet reinforced with 1PLY fabric insertion. This glassfiber coated silicone rubber material offers exceptional durability and thermal performance for industrial applications.
Technical Specifications
Material:
100% Virgin Silicone Rubber
Surface:
Smooth/Smooth
Tensile Strength:
7-12 MPa
Elongation:
330%-740%
Density:
1.25 g/cm³
Temperature Range:
-60°C to +260°C
Hardness:
40, 50, 60, 70 ±5 Shore A
Tear Strength:
26-42 N/mm
Standard Sizes
| Thickness | Width | Length | Ply |
|---|---|---|---|
| 1.0mm | 1.2m | 10m | 1PLY |
| 1.5mm | 1.2m | 10m | 1PLY |
| 2.0mm | 1.2m | 10m | 1PLY |
| 3.0mm | 1.2m | 10m | 2PLY |
| 4.0mm | 1.2m | 10m | 2PLY |
| 5.0mm | 1.2m | 10m | 2PLY |
Custom OEM sizes available upon agreement.
Product Features
- Available in various lengths and widths, cut to customer requirements
- Insertion options: reinforced with 1PLY or 2PLY aramid or glassfiber fabric
- Available colors: Black, Red, Green, White, Grey, and others
- Thickness range: 0.5-6.0mm
- Maximum width: 3.6m
- Length: 10-20m or custom requirements
- Surface options: Smooth or fabric surface
- Insertion materials: Cloth, metal mesh, or nylon cloth
Additional Information
- Packing: Plastic film and pallet
- H.S. Code: 3920999090
- Productivity: 100 tons/month
- Origin: China
- Transportation: By Sea or By Air
- Minimum Order: 10 rolls
