0.1-1.0mm Transparent Silicone Rubber Sheet 50m Roll 40-70 Shore A

  • 0.1-1.0mm Transparent Silicone Rubber Sheet 50m Roll 40-70 Shore A
  • 0.1-1.0mm Transparent Silicone Rubber Sheet 50m Roll 40-70 Shore A
  • 0.1-1.0mm Transparent Silicone Rubber Sheet 50m Roll 40-70 Shore A
  • 0.1-1.0mm Transparent Silicone Rubber Sheet 50m Roll 40-70 Shore A
  • 0.1-1.0mm Transparent Silicone Rubber Sheet 50m Roll 40-70 Shore A
Place of Origin China
Brand Name 3A Rubber
Certification ROHS/FCC/SGS
Model Number 3A1001
Minimum Order Quantity 100kgs
Price USD3-15.00/kg
Packaging Details packing in rolls, bags and pallets
Delivery Time 10-20 working days after received your payment
Payment Terms T/T,L/C,Paypal,Western Union,D/P,MoneyGram
Supply Ability 100000kgs per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Thickness 0.1-1.0mm Width 0.5-1.0m
Length 50, 100m Material Plastic+silicone+PET
Color Transparent Application Gaskets, Seals, Insulation, Cushioning
Hardness 40, 50, 60, 70shore A Elongation 300%
Tensile Strength 7.0Mpa Tear Strength 26N/mm
Working Temperature -60°C - +240°C Working Temp -40^C ~ +260^C
Aging Resistance Excellent Chemical Resistance Excellent
Rohs Compliance Yes Oem OEM Service Available
Electrical Isolation Excellent Process Extrusion
Feature Heat Conducting,High Pressure Resistance
Highlight

silicone gasket sheet

,

flexible rubber sheet
Leave a Message
Product Description
0.1-1.0mm x 0.5-1.0mm x 50m Super Thin Transparent Silicone Rubber Sheet Silicone Film Silicone Rolls
Super thin silicone film, silicone rubber sheet, silicone roll
Standard Sizes
0.1±0.05mm x 0.5m x 50m
0.2±0.05mm x 0.5m x 50m
0.3±0.05mm x 0.5m x 50m
0.4±0.05mm x 0.5m x 50m
0.5±0.05mm x 0.5m x 50m
0.6±0.05mm x 0.5m x 50m
0.7±0.05mm x 0.5m x 50m
0.8±0.05mm x 0.5m x 50m
1.0±0.05mm x 0.5m x 50m
0.1±0.05mm x 1.0m x 50m
0.2±0.05mm x 1.0m x 50m
0.3±0.05mm x 1.0m x 50m
0.4±0.05mm x 1.0m x 50m
0.5±0.05mm x 1.0m x 50m
0.6±0.05mm x 1.0m x 50m
0.7±0.05mm x 1.0m x 50m
0.8±0.05mm x 1.0m x 50m
1.0±0.05mm x 1.0m x 50m
Packaging & Delivery
Packaging Details Standard export packaging
Delivery Detail Within 7 days
Specifications
Ordinary Matte Surface Protective Transparent Silicone Film
  • High resistance to tear
  • High temperature resistance
  • Corrosion resistance
Transparent silicone pad
Material High grade silicone material
Specification 0.1-1.0mm x 500-1000mm x 50m or as your requirement
Specific gravity 1.25
Tearing 7.0Mpa
Tension 300%
Hardness 40, 50, 60, 70 ±5shore A
Elongation at break ≥ 300%
Linear shrinkage 3.60%
Temperature range -60°C to +240°C
Luster Silicon rubber sheets with all kinds of luster, fresh and bright
Performance
High resistance to tear performance, high temperature resistance, corrosion resistance, anti-aging performance, non-toxic, odorless, elasticity, insulation, environmentally friendly.
Applications
  • Can be punched into gaskets, washers, seals with excellent sealing performance for medicine, industry and food industry applications, suitable for pressure-demanding environments
  • Widely used in LCD screens of computers, time clocks, fax machines, printers within high temperature components
  • Automotive mechanical body, kitchen appliances, home appliances and other equipment sealing
0.1-1.0mm Transparent Silicone Rubber Sheet 50m Roll 40-70 Shore A 0 0.1-1.0mm Transparent Silicone Rubber Sheet 50m Roll 40-70 Shore A 1
