0.1 1.0mm x 0.5 1.0mm x 50m Super Thin Transparent Silicone Rubber Sheet Silicone Film Silicone Rolls
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ROHS/FCC/SGS |
| Model Number | 3A1001 |
| Minimum Order Quantity | 100kgs |
| Price | USD3-15.00/kg |
| Packaging Details | packing in rolls, bags and pallets |
| Delivery Time | 10-20 working days after received your payment |
| Payment Terms | T/T, L/C, Paypal, Western Union, D/P, MoneyGram |
| Supply Ability | 100000kgs per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Thickness | 0.1-1.0mm | Width | 0.5-1.0m |
|---|---|---|---|
| Length | 50, 100m | Material | Plastic+silicone+PET |
| Color | Transparent | Application | Gaskets, Seals, Insulation, Cushioning |
| Hardness | 40, 50, 60, 70shore A | Elongation | 300% |
| Tensile Strength | 7.0Mpa | Tear Strength | 26N/mm |
| Working Temperature | -60°C - +240°C | Working Temp | -40^C ~ +260^C |
| Aging Resistance | Excellent | Chemical Resistance | Excellent |
| Rohs Compliance | Yes | Oem | OEM Service Available |
| Electrical Isolation | Excellent | Process | Extrusion |
| Feature | Heat Conducting,High Pressure Resistance | ||
| Highlight | silicone gasket sheet,flexible rubber sheet |
||
Product Description
0.1 - 1.0mm x 0.5 - 1.0mm x 50m super thin silicone rubber sheet , silicone film , silicone rolls
super thin silicone film, silicone rubber sheet, silicone roll
Standard Size:
0.1+/-0.05mm x 0.5m x 50m
0.2+/-0.05mm x 0.5m x 50m
0.3+/-0.05mm x 0.5m x 50m
0.4+/-0.05mm x 0.5m x 50m
0.5+/-0.05mm x 0.5m x 50m
0.6+/-0.05mm x 0.5m x 50m
0.7+/-0.05mm x 0.5m x 50m
0.8+/-0.05mm x 0.5m x 50m
1.0+/-0.05mm x 0.5m x 50m
0.1+/-0.05mm x 1.0m x 50m
0.2+/-0.05mm x 1.0m x 50m
0.3+/-0.05mm x 1.0m x 50m
0.4+/-0.05mm x 1.0m x 50m
0.5+/-0.05mm x 1.0m x 50m
0.6+/-0.05mm x 1.0m x 50m
0.7+/-0.05mm x 1.0m x 50m
0.8+/-0.05mm x 1.0m x 50m
1.0+/-0.05mm x 1.0m x 50m
Packaging & Delivery
| Packaging Details: | standard export packaging |
| Delivery Detail: | within 7days |
Specifications
Ordinary Matte Surface Protective Transparent Silicone Film
1. High Resistance To Tear
2. High Temperature Resistance
3. Corrosion Resistance
Transparent silicone pad
|
Material |
high grade silicone material |
|
Specification |
0.1- 1.0mm x 500~1000mm x 50m or as your requirement |
| specific gravity | 1.25 |
| Tearing | 7.0Mpa |
| Tension | 300% |
| Hardness | 40, 50, 60, 70 ±5shore A |
| Elongation at break | ≥ 300% |
| Linear shrinkage | 3.60% |
| Temperature | from -60 to +240 degrees |
| Luster | silicon rubber sheets with all kinds of luster, fresh and bright |
Performance: has a high resistance to tear performance, high temperature resistance, corrosion resistance, anti-aging performance, non-toxic, odorless, elasticity, insulation, green.
Application:
a) Can be punched gaskets, washers, seals, sealing performance, for medicine, industry and the food industry, and suitable for pressure demanding environment;
b) Transparent silicone pad are also widely used: at the LCD screen of the computer, time clocks, computer; fax machines, printers within a high temperature components; automotive mechanical body, kitchen appliances, home appliances and other equipment sealed.
