Food Grade High Tear Resistant Silicone Rubber Sheet with Wide Temperature Range for Industrial Applications
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ROHS/FCC/SGS |
| Model Number | 3A1001 |
| Minimum Order Quantity | 200kgs |
| Price | USD3-15.00/kg |
| Packaging Details | packing in rolls, bags and pallets |
| Delivery Time | 7-15days after receive the buyer's payment |
| Payment Terms | T/T,L/C,Paypal,Western Union,D/P |
| Supply Ability | 100000kgs per month |
Product Details
| Adhesive Backing | Yes, Custom | Chemical Resistance | Good |
|---|---|---|---|
| Temperature Range | -40℃ To 230℃ | Dielectric Strength | 20-30KV/mm |
| Tear Resistance | Excellent | Material | 100% Virgin Silicone Rubber |
| Tensilestrength | 12Mpa | Grade | Food Grade Without Smell |
| Application | Industry Sealing | Quality | Middle Tear Resistant |
| Flameresistance | UL94V-0 | Surface | Smooth, Sand Or Impression Fabric |
| Color | Transparent, Translucent, Dark Red, Black, Milk White, Grey, Blue Etc. | Reinforce | Agree To Insert 1 PLY Fabric |
| Tensile Strength | 7-12Mpa | Hardness | 10-80shore A |
| Elongation | 350%-720% | Density | 1.25-1.50g/cm3 |
| Tear Strength | 26-42N/mm | Working Temperature | -60°C - +260°C(moment 300°C) |
| Thickness | 0.1-50mm | Width | 0.1-3.6m |
| Length | 0.1-100m | Working Temp | -40^C ~ +260^C |
| Type | Bag Or Bucket | Agingresistance | Excellent |
| Highlight | silicone gasket sheet,flexible rubber sheet |
||
Product Description
0.5-6.0mm x 0.5-1.2m x 10/20m Silicone Rubber Sheet
Premium silicone rubber sheets and rolls manufactured using 100% virgin silicone rubber. Available in food grade formulations without odor, suitable for both industrial food processing and general industrial applications.
Product Specifications
| Material | 100% virgin HTV silicone rubber or liquid silicone |
| Available Grades | Industrial grade, food grade, medical grade, FDA grade postcured |
| Quality Types | High tear resistant, middle tear resistant |
| Color Options | Transparent, translucent, dark red, black, milk white, grey, blue, and others |
| Surface Finishes | Smooth/smooth, smooth/impression fabric, smooth/sand, or double impression fabric |
| Reinforcement | Insert 1 PLY fabric available |
| Tensile Strength | 7-12 MPa |
| Hardness Range | 10, 20, 30, 40, 50, 60, 70, 80 ±5 Shore A |
| Elongation | 350%-720% |
| Density | 1.25-1.50 g/cm³ |
| Tear Strength | 26-42 N/mm |
| Working Temperature | -60°C to +260°C (momentary maximum 300°C) |
Standard Dimensions
- 1.2mm x 330mm x 330mm
- 1.7mm x 330mm x 330mm
- 2.0mm x 330mm x 330mm
- 2.2mm x 330mm x 330mm
- 0.1-2.0mm x 0.5-1.1m x 25/50/100/200m
- 0.5-6.0mm x 0.5-1.2m x 10/20m
- 1.0-50.0mm x 0.5/1.0/1.2m x 10m
- 1.0-6.0mm x 1.5-3.8m x 10m
- OEM sizes available upon request
Press Compatibility
German Silicone: Compatible with "+" and "-" press on wooden PVC vacuum laminators
Chinese Silicone: Compatible with "-" press only on wooden PVC vacuum laminators
Chinese Silicone: Compatible with "-" press only on wooden PVC vacuum laminators
Specialized Products
Available in FDA grade silicone rubber sheets with postcure treatment and antistatic silicone sheets with fire-resistant properties, typically in black color with smooth surface finish.
Inquiry Requirements: When requesting a quote, please specify your application, required color, hardness, dimensions, and quantity.
Manufacturing Excellence
Our silicone rubber sheets are manufactured using high-quality silicone rubber on drum-type vulcanizing presses or standard vulcanizing presses, tailored to meet specific customer requirements. Through advanced management, innovative techniques, and strict quality control using premium silicone materials and machinery, we have overcome limitations associated with traditional manufacturing methods.
We successfully eliminate issues with lower smooth surface quality and high thickness tolerance found in ROTOCURE vulcanizing machines, as well as restrictions on width, length, and visible joints common in press vulcanizing machines. Our products feature seamless construction with virtually unlimited length capabilities.
Our super-wide drum-type vulcanizing press accommodates widths up to 4000mm, enabling production of high-quality silicone sheets up to 3600mm wide without joints.
Material Properties
High-quality silicone rubber with excellent performance characteristics including anti-aging, ozone resistance, heat resistance, electric insulation, oil resistance, solvent resistance, corrosion resistance, non-toxic and odorless properties, and environmental safety.
Suitable for operation in air, water, oil, and other media within temperature ranges of -60°C to +260°C (momentary maximum 300°C). Provides high stability, reliability, and surface inactivity without stickiness.
Applications
Ideal for punching various rubber seal gaskets and specialized applications including PVC vacuum laminating presses, wooden door vacuum laminating presses, glass vacuum laminating presses, solar vacuum laminating presses, hot laminating presses, and card laminating presses.
