Food Grade Silicone Rubber Sheet 0.5-6.0mm x 0.5-1.2m -60°C to 260°C
Place of Origin | China |
---|---|
Brand Name | 3A Rubber |
Certification | ROHS/FCC/SGS |
Model Number | 3A1001 |
Minimum Order Quantity | 200kgs |
Price | USD3-15.00/kg |
Packaging Details | packing in rolls, bags and pallets |
Delivery Time | 7-15days after receive the buyer's payment |
Payment Terms | T/T,L/C,Paypal,Western Union,D/P,MoneyGram |
Supply Ability | 100000kgs per month |

Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
Material | 100% Virgin Silicone Rubber | Grade | Food Grade Without Smell |
---|---|---|---|
Quality | Middle Tear Resistant | Surface | Smooth, Sand Or Impression Fabric |
Color | Transparent, Translucent, Dark Red, Black, Milk White, Grey, Blue Etc. | Reinforce | Agree To Insert 1 PLY Fabric |
Tensile Strength | 7-12Mpa | Hardness | 10-80shore A |
Elongation | 350%-720% | Density | 1.25-1.50g/cm3 |
Tear Strength | 26-42N/mm | Working Temperature | -60°C - +260°C(moment 300°C) |
Thickness | 0.1-50mm | Width | 0.1-3.6m |
Length | 0.1-100m | Working Temp | -40^C ~ +260^C |
Type | Bag Or Bucket | Agingresistance | Excellent |
Adhesive Backing | Yes, Custom | Chemical Resistance | Good |
Temperature Range | -40℃ To 230℃ | Dielectric Strength | 20-30KV/mm |
Tear Resistance | Excellent | Tensilestrength | 12Mpa |
Application | Industry Sealing | Flameresistance | UL94V-0 |
Highlight | silicone gasket sheet,flexible rubber sheet |
Product Description
0.5-6.0mm x 0.5-1.2m x 10/20m Silicone Rubber Sheet
Premium Silicone Sheeting for Industrial & Food Applications
High-performance silicone rubber sheets and rolls manufactured from 100% virgin silicone rubber. Available in food grade (odorless) and industrial grade formulations to meet diverse application requirements.
Key Features
- Made with 100% virgin HTV or liquid silicone rubber
- Available in multiple grades: industrial, food, medical, and FDA postcured
- High tear resistance with customizable strength levels
- Excellent temperature resistance (-60°C to +260°C, momentary 300°C)
- Non-toxic, tasteless, and pollution-free composition
- Superior resistance to aging, ozone, oils, solvents, and corrosion
Technical Specifications
Property | Specification |
---|---|
Material | 100% virgin HTV silicone rubber or liquid silicone |
Available Colors | Transparent, translucent, dark red, black, milk white, grey, blue |
Surface Options | Smooth/smooth, smooth/impression fabric, smooth/sand, double impression fabric |
Reinforcement | Optional 1 PLY fabric insert |
Tensile Strength | 7-12Mpa |
Hardness (Shore A) | 10, 20, 30, 40, 50, 60, 70, 80 ±5 |
Elongation | 350%-720% |
Density | 1.25-1.50g/cm³ |
Tear Strength | 26-42N/mm |
Standard Sizes
- 0.1-2.0mm x 0.5-1.1m x 25/50/100/200m
- 0.5-6.0mm x 0.5-1.2m x 10/20m
- 1.0-50.0mm x 0.5/1.0/1.2m x 10m
- 1.0-6.0mm x 1.5-3.8m x 10m
- Custom OEM sizes available
Specialized Options
- FDA grade silicone rubber sheet with postcure treatment
- Antistatic silicone sheets with fire-resistant properties
- Black color with smooth surface options
- Germany silicone for "+" and "-" press applications
- Chinese silicone for "-" press applications
Manufacturing Excellence
Produced using drum-type vulcanizing press technology to ensure superior quality with:
- Exceptional surface smoothness and precise thickness tolerance
- Seamless construction without visible joints
- Maximum width of 3600mm without joints
- Infinite length capability
Application Areas
Ideal for use in air, water, oil and other media environments. Commonly used for:
- PVC vacuum laminating presses
- Wooden door vacuum laminating presses
- Glass vacuum laminating presses
- Solar vacuum laminating presses
- Hot laminating presses
- Card laminating presses
- Rubber seal gasket production
When requesting a quote, please specify your application requirements, preferred color, hardness, dimensions, and quantity.
