Heat-Resistant Silicone Rubber Sheet for Extreme Temperature Environments with UL94-V0 Flammability
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ISO9001 |
| Model Number | 3A1001 |
| Minimum Order Quantity | 100kgs |
| Price | USD3.00-15.80/kg |
| Packaging Details | Packing in rolls and pallets |
| Delivery Time | 7-15days after receive the buyer's payment |
| Payment Terms | T/T,L/C,D/P,Western Union,Paypal |
| Supply Ability | 500000kgs/month |
Product Details
| Thickness | 0.2mm-50mm | Specific Gravity | 1.5g/cm3 |
|---|---|---|---|
| Hardness | 20-80 Shore A | Aging Resistance | Excellent |
| Flammability | UL94-V0 | Name | Silicone Rubber Sheet |
| Elongation | 300-700% | Ozone Resistance | Excellent |
| AgingResistance | Excellent | Application | Electrical Insulation, Sealing, Etc. |
| Color | Black, White, Red, Etc. | DielectricStrength | 20kv/mm |
| Elongation | 400% | FlameResistance | UL94V-0 |
| Hardness | 30-80ShoreA | Length | 1m-20m |
| Material | Silicone Rubber | OperatingTemperature | -60℃ To +200℃ |
| TearStrength | 25N/mm | TensileStrength | 6.2Mpa |
| Thickness | 0.1mm-50mm | Width | 0.5m-2m |
| Highlight | 1m length transparent silicone rubber sheet,heat press transparent silicone rubber sheet,20m length silicone rubber sheet roll |
||
Product Description
Heat-Resistant Silicone Rubber Sheet for Extreme Temperature Environments
Product Overview
Silicone Rubber Sheet is a versatile rubber sheeting made of silicone, widely used for various purposes. It offers excellent ozone resistance and is available in multiple colors including translucent, white, black, red, and blue. The sheets feature hardness ranging from 20 to 80 Shore A, specific gravity from 1.2 to 1.5g/cm³, and tensile strength of 6 to 12Mpa.
Key Features
- Product Name: Silicone Rubber Sheet
- Hardness: 20-80 Shore A
- Specific Gravity: 1.2-1.5g/cm³
- Temperature Range: -60°C to +260°C
- Color: Translucent, White, Black, Red, Blue, Etc.
- Width: 0.5m-3.6m
- High Temp Silicone Sheet
- Silicone Rubber Sheet Roll
Technical Specifications
| Name | Silicone Sheet |
|---|---|
| Color | Translucent, White, Black, Red, Blue, Etc. |
| Specific Gravity | 1.2-1.5g/cm³ |
| Material | Silicone Rubber |
| Hardness | 20-80 Shore A |
| Ozone Resistance | Excellent |
| Tensile Strength | 6-12Mpa |
| Length | 1m-20m |
| Width | 0.5m-3.6m |
| Elongation | 300-700% |
Applications
Silicone rubber sheet is a popular and versatile material used across multiple industries including automotive, aerospace, medical, electrical, and industrial applications. It provides excellent insulation, heat resistance, chemical resistance, electrical insulation, flexibility, fire resistance, temperature resistance, and dimensional stability. The material is lightweight, durable, and highly resistant to tearing.
Customization Options
- Brand Name: 3A Rubber
- Model Number: 3A1001
- Place of Origin: China
- Certification: ISO9001
- Minimum Order Quantity: 100kgs
- Price: USD3.00-15.80/kg
- Thickness: 0.2mm-50mm
- Temperature Range: -60°C to +260°C
- Tensile Strength: 6-12Mpa
- Specific Gravity: 1.2-1.5g/cm³
- Width: 0.5m-3.6m
Packaging & Shipping
Silicone rubber sheets are typically packaged in rolls wrapped in protective plastic film, or in boxes/pallets depending on size and quantity. Shipping options include air freight for faster delivery or ocean freight for cost-effective transportation with longer transit times.
Support & Services
We provide comprehensive technical support including product selection, installation guidance, and maintenance advice. Our experienced staff offers assistance with material properties, fabrication methods, and optimization techniques. After-sales service and troubleshooting assistance ensure optimal product performance.
Frequently Asked Questions
Q: What is the brand name of the Silicone Rubber Sheet?
A: The brand name of the Silicone Rubber Sheet is 3A Rubber.
Q: What is the model number of the Silicone Rubber Sheet?
A: The model number of the Silicone Rubber Sheet is 3A1001.
Q: Where is the Silicone Rubber Sheet from?
A: The Silicone Rubber Sheet is from China.
Q: Is the Silicone Rubber Sheet certified?
A: Yes, the Silicone Rubber Sheet is certified with ISO9001.
Q: What is the minimum order quantity of the Silicone Rubber Sheet?
A: The minimum order quantity of the Silicone Rubber Sheet is 100kgs.
