1.5mm Close Cell Silicone Foam Strip High Temperature Resistant Silicone Sponge Strip
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ISO9001 |
| Model Number | 3A1002 |
| Minimum Order Quantity | 100kgs/month |
| Price | USD6.00-10.00/kg |
| Packaging Details | packing in rolls and cartons |
| Delivery Time | 7-15days after receive the buyer's payment |
| Payment Terms | L/C,D/P,T/T,Western Union |
| Supply Ability | 100000kgs/month |
Product Details
| Commodity | Silicone Sponge Sheet | Name | Close Cell 1.5mm Silicone Foam Strips , Silicone Sponge Strip |
|---|---|---|---|
| Cell | Close Cell | Surface | Impression Fabric |
| Quality | Superior | Hardness | 10-40shore A |
| Density | 0.4-1.0g/cm3 | Thickness | 1.5-50mm |
| Width | 0.1-1.5m | Length | 0.1-10m |
| Oem | OEM Service Available | Drawing | 2D Or 3D |
| Working Temp | -40^C ~ +260^C | Flammability | UL94-V0 |
| Origin | China | Backing Adhesive | Agreed |
| Highlight | 1.5mm silicone foam strips,close cell silicone foam strips,1.5mm silicone sponge rubber sheet |
||
Product Description
Close Cell 1.5mm Silicone Foam Strips, Silicone Sponge Strip
Product Overview
Close Cell Silicone Sponge Sheet and Silicone Foam Sheet available in red, white, and other colors. Manufactured using specialized continuous plain press vulcanizer technology with high-quality closed cell silicone sponge material.
Key Features
- Excellent high temperature resistance and aging resistance
- Superior ozone resistance and heat insulation properties
- Resistant to fuel oil and lubricants
- Odorless with high durability
- High compressibility with low compression set
- Excellent acoustic and thermal insulation properties
- Operating temperature range: -60°C to +220°C for continuous use
- Intermittent use range: -70°C to +260°C
Performance Parameters
| Property | Unit | Data | Standard |
|---|---|---|---|
| Breaking Strength | Kn/m | 55 | ASTM D1458 |
| Strength | psi | 200 | ASTM D421 |
| Elongation | % | 150 | ASTM D421 |
| Hardness | shore A | 25±3 | ASTM 2240 |
| Temperature Range | ℃ | -60-250 | En344 |
| Specific Gravity | g/cm³ | 0.8 | ASTM D762 |
| Heat Conductivity | W/m-k | 0.9 | ASTM D5470 |
| Puncture Voltage | VAC | >3000 | ASTM D149 |
Specifications
- Material: Virgin silicone sponge, silicone foam
- Cell Type: Closed cell
- Available Colors: Dark red, white, grey, black, beige, brown, blue, etc.
- Surface: Double impression fabric, smooth
- Tensile Strength: 100-200 PSI
- Hardness: 10, 15, 20, 25, 30, 35, 40+/-5 shore A (currently 20-25 shore A)
- Elongation: 100%
- Density: 0.48-1.00 g/cm³
- Working Temperature: -60°C to +220°C (momentary 260°C)
- Thickness: 1.5-50 mm
- Width: 0.1-1.5 m (maximum 1.5 m @ more than 5 mm thickness)
- Length: 0.1-10 m
Standard Sizes
- 1.5-50 mm * 1.0 m * 10 m
- 1.5-50 mm * 1.2 m * 10 m
- 5.0-50 mm * 1.5 m * 10 m
Density by Hardness
- 10 shore A: Density 0.48-0.50 g/cm³
- 15 shore A: Density 0.50-0.55 g/cm³
- 20-25 shore A: Density 0.60-0.65 g/cm³
- 25-30 shore A: Density 0.65 g/cm³
- 30-40 shore A: Density 1.00 g/cm³
Additional Options
- OEM & customized sizes available
- Packing options: cartons, rolls, pallets, or crates
- Backing adhesive available with Chinese general glue or USA 3M glue
- Perforated silicone sponge sheet: 6, 8, 10 mm * 0.9 m * 1.8 m in red, beige, white
- Custom sizes for silicone sponge extrusion, profile, and stripe applications
For more data & information, please contact:
When inquiring, please confirm: hardness, color, size, and quantity requirements.
