Food Grade 7.5Mpa Tensile Strength Silicone Tube Without Smell for Air and Water

  • Food Grade 7.5Mpa Tensile Strength Silicone Tube Without Smell for Air and Water
  • Food Grade 7.5Mpa Tensile Strength Silicone Tube Without Smell for Air and Water
  • Food Grade 7.5Mpa Tensile Strength Silicone Tube Without Smell for Air and Water
  • Food Grade 7.5Mpa Tensile Strength Silicone Tube Without Smell for Air and Water
  • Food Grade 7.5Mpa Tensile Strength Silicone Tube Without Smell for Air and Water
  • Food Grade 7.5Mpa Tensile Strength Silicone Tube Without Smell for Air and Water
Place of Origin China
Brand Name 3A Rubber
Certification ISO9001
Model Number 3A1003
Minimum Order Quantity 20kgs
Price USD3-15.00/kg
Packaging Details Packing in rolls, cartons and pallets
Delivery Time 7-15days
Payment Terms L/C,D/P,T/T,Western Union,D/P
Supply Ability 100000kgs/month
Product Details
Name Silicone Tube Keyword Silicone Tube
Material Food Grade Silicone Application For Air And Water
Color Transparent Tensile Strength 7.5Mpa
Elongation 400% - 600% Density 1.25g/cm3
Working Press 10kgs Quality Industrial Grade
Elongation At Break 300-600% Rohs Compliant Yes
Uv Resistance Good Surface Smooth
Resistant 18-25KV/mm Certifications FDA, RoHS, REACH
Oem Odm Available Shape Tube
Temperature Range -60°C To +200°C Working Temperature -60°C - +260°C(moment 300°C)
Hardness Shore A 50
Highlight

food grade braided silicone tubing

,

7.5mpa braided silicone tubing

,

without smell silicone braided hose pipe
Leave a Message
Product Description
Food Grade 7.5mpa Braided Silicone Tubing Without Smell
Food Grade Silicone Tube, Silicone Hose, Silicone Tubing Without Smell

Our silicone hose, silicone tube, and silicone sleeve products are extruded or molded using specialized equipment with high-quality silicone materials. Manufactured according to customer specifications with precise inside and outside diameter molds, these products feature high tensile strength, excellent flexibility, strong anti-pull properties, and a wide range of hardness options with superior aging resistance.

These silicone hoses demonstrate excellent resistance to ozone, heat, insulation properties, fuel oil, and lubricants. They operate effectively in air, water, or oil media within temperature ranges of -60°C to +250°C.

Our product range includes:

  • Industrial Grade: Made with standard extruded silicone and vulcanized with imported peroxide - odorless
  • Food Grade: Manufactured with food-grade transparent fumed silicone, platinum vulcanized - non-toxic and tasteless
  • Medical Grade: Produced with medical-grade transparent fumed silicone, platinum vulcanized with FDA and LFGB certification

Applications include corona rollers or transfer of water, air, oil, and other media.

Specifications
Material 100% virgin silicone material
Quality Industrial grade, food grade under postcured or platinum cured
Color Transparent, translucent, dark red, orange, black, milk white, blue, grey, etc.
Surface Smooth/smooth
Fiber Reinforced Insert 1-5PLY polyester fiber
Tensile Strength 7.5-9.8Mpa
Hardness 50, 60, 70, 80+/-5 shore A
Elongation 350-720%
Density 1.25+/-0.05g/cm³
Tear Strength 26-42N/mm
Working Temperature -60°C to +250°C
Wall Thickness 1.0, 2.0, 3.0, 4.0, 5.0mm
Standard Sizes
Ø0.5mm x Ø1.0mm x 5-20kgs
Ø0.5mm x Ø1.5mm x 5-20kgs
Ø0.5mm x Ø2.0mm x 5-20kgs
Ø0.8mm x Ø1.9mm x 5-20kgs
Ø1.0mm x Ø2.0mm x 5-20kgs
Ø1.0mm x Ø3.0mm x 5-20kgs
Ø1.0mm x Ø4.0mm x 5-20kgs
Ø1.5mm x Ø2.5mm x 5-20kgs
Ø1.5mm x Ø3.0mm x 5-20kgs
Ø1.6mm x Ø3.2mm x 5-20kgs
Ø2.0mm x Ø3.0mm x 5-20kgs
Ø2.0mm x Ø4.0mm x 5-20kgs
Ø2.0mm x Ø5.0mm x 5-20kgs
Ø2.0mm x Ø6.0mm x 5-20kgs
Ø3.0mm x Ø4.0mm x 5-20kgs
Ø3.0mm x Ø5.0mm x 5-20kgs
Ø3.0mm x Ø6.0mm x 5-20kgs
Ø3.0mm x Ø8.0mm x 5-20kgs
Ø3.0mm x Ø9.0mm x 5-20kgs
Ø4.0mm x Ø5.0mm x 5-20kgs
Ø4.0mm x Ø6.0mm x 5-20kgs
Ø4.0mm x Ø7.0mm x 5-20kgs
Ø4.0mm x Ø8.0mm x 5-20kgs
Ø5.0mm x Ø8.0mm x 5-20kgs
Ø5.0mm x Ø9.0mm x 5-20kgs
Ø5.0mm x Ø10.0mm x 5-20kgs
Ø6.0mm x Ø9.0mm x 5-20kgs
Ø6.0mm x Ø10.0mm x 5-20kgs
Ø6.0mm x Ø12.0mm x 5-20kgs
Ø7.0mm x Ø9.0mm x 5-20kgs
Ø7.0mm x Ø10.0mm x 5-20kgs
Ø7.0mm x Ø12.0mm x 5-20kgs
Ø8.0mm x Ø10.0mm x 5-20kgs
Ø8.0mm x Ø12.0mm x 5-20kgs
Ø8.0mm x Ø14.0mm x 5-20kgs
Ø9.0mm x Ø12.0mm x 5-20kgs
Ø9.0mm x Ø14.0mm x 5-20kgs
Ø9.0mm x Ø16.0mm x 5-20kgs
Ø10.0mm x Ø14.0mm x 5-20kgs
Ø10.0mm x Ø16.0mm x 5-20kgs
Ø10.0mm x Ø18.0mm x 5-20kgs
Ø12.0mm x Ø16.0mm x 5-20kgs
Ø12.0mm x Ø18.0mm x 5-20kgs
Ø12.0mm x Ø20.0mm x 5-20kgs
Ø14.0mm x Ø18.0mm x 5-20kgs
Ø14.0mm x Ø20.0mm x 5-20kgs
Ø14.0mm x Ø22.0mm x 5-20kgs
Ø16.0mm x Ø18.0mm x 5-20kgs
Ø16.0mm x Ø20.0mm x 5-20kgs
Ø20.0mm x Ø30.0mm x 5-20kgs
Ø30.0mm x Ø40.0mm x 5-20kgs
Ø40.0mm x Ø50.0mm x 5-20kgs

OEM & customized sizes available upon agreement. Packing options include rolls, bags, cartons, pallets, or crates.

For more data & information, please email to: sales@3Arubber.com

When you enquire, please confirm the hardness, color, size and quantity

Food Grade Silicone Fiber Hose Specifications
Item Silicone fiber hose, silicone braided hose, silicone reinforced hose
Material Food grade silicone material
Reinforced Braided polyester fiber
Color Transparent, red, blue, black or as per buyer's request
Surface Smooth
Tensile Strength 7.5-9.8Mpa
Hardness 50-70 shore A
Elongation 300%
Density 1.25g/cm³
Working Pressure 10Kgs
Minimum Working Temperature -30°C
Maximum Working Temperature +250°C
ID (Inside Diameter) 4~50mm
Wall Thickness 3~5mm
Tolerance ID less than 1/2": ±0.3mm; ID more than 1/2": ±0.5mm
Available Sizes for Reinforced Hose
ID4mm x OD9mm
ID5mm x OD11mm
ID6mm x OD10mm
ID6mm x OD12mm
ID7.5mm x OD14.5mm
ID8mm x OD12mm
ID8mm x OD14mm
ID8mm x OD16mm
ID9mm x OD15mm
ID10mm x OD15mm
ID10mm x OD17mm
ID10mm x OD18mm
ID10mm x OD19.5mm
ID12mm x OD20mm
ID12.7mm x OD20mm
ID13mm x OD19mm
ID13mm x OD20mm
ID13mm x OD21mm
ID16mm x OD24mm
ID19mm x OD27mm
ID19mm x OD28mm
ID19.5mm x OD27.5mm
ID22mm x OD32mm
ID25mm x OD35mm
ID32mm x OD42mm
ID38mm x OD46mm
ID38mm x OD48mm
ID50mm x OD60mm

Properties: Anti-aging, erosion-endurable, high temperature resistance, anti-shock, etc.

Advantages: Customized + high performance + high quality + favorable price + rich experience

Food grade silicone tubing product display Silicone hose close-up showing smooth surface Braided silicone tubing cross-section view Silicone hose manufacturing quality inspection Food grade silicone tubing applications Industrial silicone hose specifications Silicone tubing packaging and shipping
