Close Cell Silicone Rubber Sheet with High Temperature Resistance and Double Impression Fabric Surface
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ISO9001 |
| Model Number | 3A1002 |
| Minimum Order Quantity | 100kgs |
| Price | USD3-15.00/kg |
| Packaging Details | packing in rolls, bags and pallets |
| Delivery Time | 7-15days after receive the buyer's payment |
| Payment Terms | L/C,D/P,T/T,Western Union |
| Supply Ability | 100000kgs/month |
Product Details
| Material | Close Cell Silicone Sponge | Color | Red, White, Black, Grey |
|---|---|---|---|
| Surface | Double Impression Fabric | Hardness | 10-40shore A |
| Tensile Strength | 200psi | Elongation | 100% |
| Density | 0.5-1.0g/cm3 | Working Temp. | -40^C ~ +260^C |
| Name | Closed Cell Silicone Foam Sheet Double Impression Fabric | Keyword | Closed Cell Silicone Foam Sheet |
| Service | OEM ODM | Working Temperaturing | -60℃-+260℃ |
| Working Temp | -40^C ~ +260^C | Temperature Range | -60°C - +260°C(moment 300°C) |
| Customization | Size, Color, Printing | Cell | Close Cell |
| Breakdown Voltage | ≥20KV/mm | Others | As Per Buyer's Drawing |
| Type | Bag Or Bucket | Operatingtemperature | -60℃ To +200℃ |
| Backing Adhesive | Agreed | Surface Treatment | Smooth, Embossed, Etc. |
| Fda Compliant | No | Origin | China |
| Rubber Name | Silicon Sponge Sheet | ||
| Highlight | 100psi closed cell silicone sponge sheet,oem closed cell silicone foam sheet,100psi closed cell silicone foam sheet |
||
Product Description
Close Cell Silicone Rubber Sheet for Heat Insulation and Protection
Product Overview
1.5-50mm x 0.1-1.5m x 1-10m Close Cell Silicone Sponge Sheet, Silicone Foam Sheet
Product Description
Our silicone sponge and foam sheets are manufactured using specialized continuous plain press vulcanizers with high-quality closed cell or open cell silicone sponge material and unique sponge techniques. These sheets offer excellent performance characteristics including high temperature resistance, aging resistance, ozone resistance, heat insulation, fuel oil resistance, lubricant resistance, odor-free composition, and exceptional durability. They feature high compressibility and low compression set across a wide working temperature range, along with superior acoustic and thermal insulation properties.
Applications & Temperature Range
Suitable for long-term continuous use at -60°C to +220°C, and intermittent use at -70°C to +260°C. Ideal for protection and heat insulation applications on various ironing tables and specialized gasket applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Material | Virgin silicone sponge, silicone foam |
| Cell Structure | Closed cell |
| Available Colors | Dark red, white, grey, black, beige, brown, blue, etc. |
| Surface Finish | Double impression fabric, smooth |
| Tensile Strength | 100-200 PSI |
| Hardness | 10, 15, 20, 25, 30, 35, 40+/-5 shore A (currently 20-25 shore A) |
| Elongation | 100% |
| Density | 0.48-1.00 g/cm³ |
| Working Temperature | -60°C to +220°C (momentary 260°C) |
| Thickness Range | 1.5-50 mm |
| Width Range | 0.1-1.5 m (maximum 1.5 m @ more than 5 mm thickness) |
| Length Range | 0.1-10 m |
Standard Sizes
- 1.5-50mm x 1.0m x 10m
- 1.5-50mm x 1.2m x 10m
- 5.0-50mm x 1.5m x 10m
Hardness & Density Correlation
- 10 shore A, density 0.48-0.50 g/cm³
- 15 shore A, density 0.50-0.55 g/cm³
- 20-25 shore A, density 0.60-0.65 g/cm³
- 25-30 shore A, density 0.65 g/cm³
- 30-40 shore A, density 1.00 g/cm³
Additional Options
- OEM & customized sizes available
- Packing options: cartons, rolls, pallets, or crates
- Backing adhesive available with Chinese general glue or USA 3M glue
- Perforated silicone sponge sheet: 6, 8, 10mm x 0.9m x 1.8m in red, beige, white
- Custom sizes for silicone sponge extrusion, profile, and stripe applications
Contact for More Information
For detailed technical data and product information, please contact:
sales@3Arubber.com
When making an enquiry, please specify the required hardness, color, size, and quantity.
