Virgin Silicone Rubber Sheet 1-6mm Thickness for Industrial Use
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ISO9001 |
| Model Number | 3A1001 |
| Minimum Order Quantity | 100kgs |
| Price | USD10.00/kg |
| Packaging Details | packing in rolls and pallets |
| Delivery Time | 7-15days after receive the buyer's payment |
| Payment Terms | L/C,,D/P,T/T,Western Union,MoneyGram |
| Supply Ability | 100000kgs/month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Virgin Silicone | Color | Translucent, Grey, Black, Blue |
|---|---|---|---|
| Surface | Smooth, Matt, Impression Fabric | Tensile Strenth | 7.5-12Mpa |
| Hardness | 10-75 Shore A | Elongation | 350-720% |
| Density | 1.25g/cm3 | Tear Strength | 26-42N/mm |
| Thickness | 1-6mm | Width | 1.5-3.6m |
| Length | 1-20m | Temperature Range | -60℃-260℃ |
| Port | Shanghai Port And Others | Finish | Smooth Or Textured Finish |
| Usage | Widely Used | Origin | Hebei, China |
| Belt Width | 500-3600mm | Others | As Per Buyer's Drawing |
| Highlight | Silicone Diaphragm,PVC Silicone Membrane,Wooden PVC Silicone Membrane |
||
Product Description
Silicone Rubber Sheet & Diaphragm for Wooden PVC Applications
Our premium silicone sheets, membranes, and rolls are manufactured using high-quality silicone material on specialized vulcanizing equipment to meet exact customer specifications. Available in various configurations to suit diverse industrial needs.
Manufacturing Capabilities
- Standard sheets (0.5-12mm thickness) produced on 4-roller rotocure vulcanizers
- Extra-wide sheets (1.0-8.0mm thickness) on 2-roller rotocure vulcanizers
- Ultra-thin sheets (0.1-1.0mm thickness) on specialized oven road vulcanizers
- Extra-thick sheets produced on plain press vulcanizers
- Maximum width of 3800mm with seamless, joint-free construction
Key Properties
- Excellent resistance to aging, ozone, heat, and chemicals
- Superior electrical insulation properties
- Non-toxic, odorless, and environmentally friendly
- Temperature range: -60°C to +260°C (peak 300°C)
- Stable performance in air, water, and oil environments
- Non-stick surface characteristics
Technical Specifications
| Material | 100% virgin HTV silicone |
|---|---|
| Available Grades | Industrial, Food, Medical, FDA (with post-curing) |
| Tensile Strength | 7.5-12.0 MPa |
| Hardness (Shore A) | 10-80 (±5) |
| Elongation | 350%-720% |
| Tear Strength | 26-42 N/mm |
| Standard Dimensions |
0.1-1.0mm × 0.3-1.0m × 25-50m 0.5-12.0mm × 0.5-1.5m × 10-20m 10.0-50.0mm × 0.5-1.5m × 1-20m 1.0-8.0mm × 1.5-3.8m × 10-20m |
Specialized Silicone Membranes
| Application | Color | Properties | Origin |
|---|---|---|---|
| Wooden PVC Vacuum Laminator ("+" & "-" press) | Grey | 9.8MPa, 40 Shore A, 750% elongation, 42N/mm tear | Germany |
| Wooden PVC Vacuum Laminator ("-" press only) | Translucent | 7.5MPa, 50 Shore A, 400% elongation, 26N/mm tear | China |
| Solar Photovoltaic Module Laminator | Grey | 12.0MPa, 60-70 Shore A, 350% elongation, 45N/mm tear | Germany |
| Safety Glass Vacuum Bags | Sky Blue/Dark Blue | 7.5-8.0MPa, 50-57 Shore A, 350-450% elongation | China |
Additional Specialized Products
- FDA grade silicone sheets with post-curing
- Antistatic silicone sheets with fire-resistant properties
- Black antistatic silicone sheets with/without 3M adhesive backing (0.2-3.0mm thickness)
For detailed specifications and inquiries:
Email: sales@3Arubber.com
Please include hardness, color, dimensions, and quantity requirements in your inquiry.
