3.6m Wide Seamless Silicone Rubber Sheet 40-60 Shore A

  • 3.6m Wide Seamless Silicone Rubber Sheet 40-60 Shore A
  • 3.6m Wide Seamless Silicone Rubber Sheet 40-60 Shore A
  • 3.6m Wide Seamless Silicone Rubber Sheet 40-60 Shore A
  • 3.6m Wide Seamless Silicone Rubber Sheet 40-60 Shore A
  • 3.6m Wide Seamless Silicone Rubber Sheet 40-60 Shore A
  • 3.6m Wide Seamless Silicone Rubber Sheet 40-60 Shore A
Place of Origin China
Brand Name 3A Rubber
Certification ISO9001
Model Number 3A1001
Minimum Order Quantity 100kgs
Price USD10.00/kg
Packaging Details packing in rolls, bags and pallets
Delivery Time 7-15days after receive the buyer's payment
Payment Terms L/C,,D/P,T/T,Western Union,MoneyGram
Supply Ability 100000kgs/month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Silicone Color Translucent, Grey, Black, Blue
Surface Smooth, Matt, Impression Fabric Tensile Strenth 7.5-12Mpa
Hardness 40-60shore A Elongation 350-720%
Density 1.25-1.30 G/cm³ Tear Strength 26-42N/mm
Thickness 1.0mm-4.0mm Width 1.5m-3.6m
Length 10-20m Quality Middle & High Tear Resistant
Application For Solar, Glass, Solar Vacuum Laminator Size Per The Buyer's Request
Temperature Resistance -60℃ To 230℃ Top Impression Fabric
Compression Set ≤25% Standard Width 0.5m,1.0m ,1.2m ,1.5m And 3.6m
Working Temperature -50-220°C Pattern One Or Two Side Smooth,one Cloth Finish
Feature Sustainable, Stocked Lead Time 7-15 Days
Products Silicone Rubber Sheet Usage Widely Used
Production Mold Compression Specific Gravity 1.25g/cm3
Highlight

3.6m Silicone Rubber Sheet

,

Silicone Diaphragm Sheet
Leave a Message
Product Description
Width 3.6m Seamless Silicone Rubber Sheet, Silicone Roll, Silicone Membrane, Silicone Diaphragm
Maximum Width 3.6m Silicone Sheet, Silicone Roll, Silicone Membrane, Silicone Diaphragm
Our high-quality silicone sheets, membranes, and rolls are manufactured using premium silicone material on specialized rotocure vulcanizers or plain press vulcanizers, tailored to meet specific dimensional requirements. We offer various production methods for different specifications:
  • Standard silicone sheets (0.5-12mm thickness, 0.5-1.5m width, 1-10m length) produced on 4-roller rotocure vulcanizers
  • Extra-wide specialty sheets (1.0-8.0mm thickness, 1.5-3.8m width, 10-20m length) produced on 2-roller rotocure vulcanizers
  • Ultra-thin specialty sheets (0.1-1.0mm thickness, 0.3-1.0m width, 25-50m length) produced on special oven road vulcanizers
  • Extra-thick sheets produced on plain press vulcanizers
Our advanced manufacturing techniques and strict quality control ensure superior products with smooth surfaces and precise thickness tolerances. Our super-wide drum-type vulcanizing press (4000mm width) enables production of seamless sheets up to 3800mm wide without joints.
Our silicone rubber features excellent properties including anti-aging, ozone resistance, heat resistance (-60°C to +260°C, momentary 300°C), electrical insulation, oil/solvent resistance, corrosion resistance, and non-toxicity. Ideal for applications in air, water, oil, and other media.
Specifications
Material 100% virgin HTV silicone material
Grade Industrial grade, food grade, medical grade, FDA grade with postcure
Quality High tear resistant, middle tear resistant, general tear resistant
Color Translucent, dark red, black, milk white, grey, blue, etc.
Surface Smooth/smooth, smooth/impression fabric, smooth/sand or double impression fabric
Reinforcement Optional: 1 PLY fiberglass fabric, aramid fabric, or wire mesh (SS201, SS304, SS316)
Tensile Strength 7.5-12.0 MPa
Hardness 10-80 Shore A (±5)
Elongation 350%-720%
Density 1.25-1.50 g/cm³
Tear Strength 26-42 N/mm
Working Temperature -60°C to +260°C (momentary 300°C)
Thickness 0.1-50 mm
Width 0.1-3.6 m
Length 1-50 m
Standard Sizes
  • 0.1-1.0mm × 0.3-1.0m × 25-50m
  • 0.5-12.0mm × 0.5-1.5m × 10-20m
  • 10.0-50.0mm × 0.5/1.0/1.2/1.5m × 1-20m
  • 1.0-8.0mm × 1.5-3.8m × 10-20m
OEM and customized sizes available. Products packed in rolls, pallets, or crates.
Special Silicone Membranes
  • Grey, 9.8 MPa, 40 Shore A, 750% elongation, 42 N/mm tear strength (Germany silicone) for "+" and "-" press on wooden PVC vacuum laminators
  • Translucent, 7.5 MPa, 50 Shore A, 400% elongation, 26 N/mm tear strength (Chinese silicone) for "-" press only on wooden PVC vacuum laminators
  • Grey, 12.0 MPa, 60-70 Shore A, 350% elongation, 45 N/mm tear strength (Germany silicone) for photovoltaic modules on solar vacuum laminators
  • Sky blue, 7.5 MPa, 50 Shore A, 350% elongation, 26 N/mm tear strength (Chinese silicone) for safety glass on glass vacuum bags and laminators
  • Dark blue, 8.0 MPa, 57 Shore A, 450% elongation, 30 N/mm tear strength (Chinese silicone) for safety glass applications
Special products available: FDA grade silicone sheets with postcure, antistatic silicone sheets with fire-resistant properties (black color, smooth surface), and black antistatic silicone sheets with optional 3M adhesive backing (thicknesses 0.2-3.0mm).
For more information, please contact: sales@3Arubber.com
When inquiring, please specify hardness, color, size, and quantity requirements.
