Food Grade Silicone Sheet 1.2m x 10m, 1-10mm Thickness

Place of Origin China
Brand Name 3A Rubber
Certification ROHS/FCC/SGS
Model Number 3A1001
Minimum Order Quantity 200kgs
Price USD3-15.00/kg
Packaging Details Packing in rolls and pallets
Delivery Time 10-20 working days after received your payment
Payment Terms T/T,L/C,Paypal,Western Union,D/P,MoneyGram,Alipay,Wechat
Supply Ability 1000000kgs per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Surface Smooth/smooth Material 100% Virgin Silicone Material
Quality Food Grade Without Smell Tensile Strength 7.5Mpa
Hardness 10-80 Shore A Elongation 350%
Density 1.25g/m3 Thickness 0.5mm, 1mm, 2mm, 3mm, 5mm, Etc.
Width 1m, 1.2mm Length 10-20m
Application For Washer, Gasket Working Temperature -40^C ~ +260^C
Temperature Range -50℃ To 200℃ Finish Smooth Or Textured Finish
Compliance FDA, LFGB, RoHS, REACH, Custom Chemical Resistance Yes
Temperature Resistance -60°C To 230°C Color Transparent, Red, Blue, Black, White, Grey, Etc.
Flameresistance UL94V-0 Gasket As Per The Buyer's Drawing
Usage Silicone Pad Rubber Name Silicon Sheet
Highlight

7.5Mpa Silicone Rubber Roll

,

10mm Silicone Rubber Sheet

,

60 Shore A Silicone Sheet

Leave a Message
Product Description
Silicone Sheet & Roll - Multiple Sizes Available
High-quality silicone sheets and rolls available in thicknesses from 1mm to 10mm, with standard dimensions of 1.2m width x 10m length. Custom sizes available upon request.
Product Specifications
Material 100% virgin HTV silicone material
Grades Available Industrial grade, food grade, medical grade, FDA grade with postcured
Quality Options High tear resistant, middle tear resistant, general tear resistant
Available Colors Translucent, dark red, black, milk white, grey, blue, etc.
Surface Finishes Smooth/smooth, smooth/impression fabric, smooth/sand or double impression fabric
Reinforcement Options Insert 1 PLY fiberglass fabric, aramid fabric or wire mesh SS201, SS304, SS316
Technical Properties
  • Tensile strength: 7.5-12.0Mpa
  • Hardness: 10-80±5 Shore A
  • Elongation: 350%-720%
  • Density: 1.25-1.50g/cm³
  • Tear strength: 26-42N/mm
  • Working temperature: -60°C to +260°C (momentary 300°C)
Standard Sizes
  • 0.1-1.0mm × 0.5m × 25/50m
  • 0.5-8.0mm × 0.5-1.2m × 10/20m
  • 1.0-30.0mm × 0.5/1.0/1.2/1.5m × 10/20m
  • 1.0-6.0mm × 1.5-3.6m × 10/20/30m
OEM and customized sizes available upon agreement. Packing options include rolls, pallets, or crates.
Special Applications
Press for Wooden Laminator:
- Translucent-grey Germany silicone membrane for "+" and "-" press on wooden PVC vacuum press laminator
- Translucent Chinese silicone membrane for "-" press only on wooden PVC vacuum press laminator
- Special FDA grade silicone sheet with postcure
- Antistatic silicone sheet with fire-resistant properties (black color, smooth surface)
Manufacturing Process
Our silicone sheets are produced using specialized vulcanization processes tailored to product requirements:
  • General silicone sheets: 4-roller rotocure vulcanizer
  • Super wide sheets: 2-roller rotocure vulcanizer
  • Super thin sheets: Special oven road vulcanizer
  • Super thick sheets: Plain press vulcanizer
Product Advantages
Our advanced manufacturing techniques and strict quality control ensure:
  • High-quality surface finish with minimal thickness tolerance
  • Wide-width production up to 3600mm without joints
  • Excellent material properties including anti-aging, ozone resistance, and heat resistance
  • Stable performance in temperatures from -60°C to +260°C
  • Non-toxic, tasteless, and pollution-free
Applications
Ideal for various industrial applications including:
  • Rubber seals and gaskets production
  • Wooden PVC vacuum press laminators
  • Wooden door vacuum press laminators
  • Safety glass vacuum laminating bags
  • Solar vacuum press laminators
  • Hot press and card press laminators
Important: When making an inquiry, please specify your application requirements, desired color, hardness, size, and quantity.
