Industrial Roller High Tear Resistant Silicone Tube Extrusion with 18-25KV/mm Resistant and Shore A 70 Hardness
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ROHS/FCC/SGS |
| Model Number | 3A1003 |
| Minimum Order Quantity | 20kgs |
| Price | negotiation |
| Packaging Details | packing in rolls, cartons and pallets |
| Delivery Time | 10-20 working days after received your payment |
| Payment Terms | T/T,L/C,Paypal,Western Union,D/P |
| Supply Ability | 100000kgs per month |
Product Details
| Material | Silicone | App | For Industrial Roller |
|---|---|---|---|
| Color | Red, Orange, White | Quality | High Tear Resistant |
| Tensile Strength | 8-12Mpa | Hardness | Shore A 70 |
| Resistant | 18-25KV/mm | Wall Thickness | 3-4mm |
| Outer Diameter | 3mm - 60mm | Rohs Compliant | Yes |
| Size | Build Mould As Per The Buyer's Drawing | Insert | Polyester |
| Shape | Tube | Working Press | 0.3-0.9Mpa |
| Produced | Extrude Or Cutting | Reinforced | Insert 1-4PLY Fabric |
| Surface | Smooth | Elongation | 400%-600% |
| Highlight | flexible silicone tubing,silicone rubber pipe |
||
Product Description
Industrial Roller Silicone Tube Extrusion OD 50 - 500mm / Silicone Pipe
Product Overview
High-quality silicone sleeve, tube, and pipe specifically designed for corona roller applications. Made from premium silicone rubber material that provides excellent resistance to high voltage and flame retardation.
Application Types
- General Purpose: Suitable for applications not requiring high pressure hoses or high compound purity levels
- Domestic & Workshop: Excellent thermal and flexibility qualities ideal for domestic appliances and hobby applications
- Medical & Food Grade: Platinum-cured, non-toxic, tasteless, odorless compounds that resist bacteria growth
- Pressure Applications: Reinforced with polyester or wire braids for vacuum or high pressure uses
Corona Machine Applications
Specifically engineered for corona machines to ensure well-proportioned high voltage corona sparkle. Enables easy color printing on plastic film with surface activation and millipore after corona treatment. Resistant to 25KV at 1mm wall thickness. Ideal for roller sleeves, high-voltage terminals, protective sleeves, and flexing tubing in various corona machines.
Technical Specifications
| Material | 100% virgin silicone from Germany Silicone |
| Available Colors | Orange, dark red, black, etc. |
| Tensile Strength | 8-12 Mpa |
| Hardness | 60-70 shore A |
| Elongation | 400%-720% |
| Density | 1.25 g/cm³ |
| Working Temperature | -60°C to +250°C |
| Voltage Resistance | 18-25 KV/mm |
| Wall Thickness | 3.0mm, 4.0mm |
Standard Sizes
Available in lengths of 10-50 meters:
Ø32mm x Ø38mm, Ø32mm x Ø40mm, Ø34mm x Ø42mm, Ø46mm x Ø54mm,
Ø50mm x Ø58mm, Ø55mm x Ø62mm, Ø60mm x Ø66mm, Ø60mm x Ø68mm,
Ø63mm x Ø71mm, Ø67mm x Ø75mm, Ø75mm x Ø83mm, Ø80mm x Ø88mm,
Ø90mm x Ø98mm, Ø98mm x Ø102mm, Ø106mm x Ø114mm, Ø140mm x Ø150mm,
Ø145mm x Ø153mm, Ø162mm x Ø172mm
Custom OEM sizes available upon agreement
Important Considerations
Silicone tubing has low resistance to steam and low tensile strength, making it prone to tearing when used with sharp-edged clamps or fittings.
When requesting a quote, please specify: color, quality requirements, hardness, size, and quantity.
