Product Details:
Place of Origin: China
Brand Name: 3A Rubber
Certification: ROHS/FCC/SGS
Model Number: 3A1001
Payment & Shipping Terms:
Minimum Order Quantity: 40m length
Price: negotiation
Packaging Details: Packing in rolls and crates
Delivery Time: 10-20 working days after received your payment
Payment Terms: T/T, L/C, Paypal, Western Union, D/P, MoneyGram, Alipay, Wechat
Supply Ability: 1000000kgs per month
Detailed Product Description
Surface: Impression Fabric, Sand On One Side Or Double Material: 100% Virgin Silicone Rubber
Quality: Food Grade Without Smell Tensile Strength: 7.5-12Mpa
Hardness: 40-70shore A Elongation: 350-720%
Density: 1.25g/m3 Thickness: 1-6.0mm
Width: 1.5-3.6m Length: 10-20m
Application: Special For Vacuum Laminator
High Light:

silicone gasket sheet

,

flexible rubber sheet

Silicone Sheet , Silicone Sheeting , Silicone Membrane , Silicone Rolls, Silicone Rubber Sheet for Vacuum Laminator





Description: the silicone sheet, silicone membrane, silicone roll are made with high quality silicone material on special rotocure vulcanizer or plain press vulcanizer according to the different request from the buyers. General silicone sheet produce on 4rollers rotocure vulcanizer, super width silicone sheet produce on 2rollers rotocure vulcanizer, super thin silicone sheet produce on special oven road vulcanizer, super thick silicone sheet produce on plain press vulcanizer. We depend on the advanced manage, innovative technique and strict quality control with excellent silicone material and vulcanizer machine, ravel out the problem of lower smooth surface and high thickness tolerance of rotocure vulcanizer machine, and also ravel out the problem of restricted width, length and visible joint on press vulcanizing machine. It is triumphantly without joint and with infinite length under the above mentioned excellence. We have the super-wide drum-type vulcanizing press with 4000mm width and high quality products maximum 3600mm width without joint. High quality silicone rubber with good performance of anti-aging, ozone resistance, heat-resistant, electric insulation, oil resistance, solvent resistance, corrosion resistant, nonpoisonous and tasteless, pollution-free. Working in air, water, oil and other medium at the temperature of -60°C - +260°C(moment maximum 300°C) with the high stability, reliability and surface inactive without sticky. Apply to punch all kinds of rubber seal, rubber gasket or special for wooden PVC vacuum press laminator, wooden door vacuum press laminator, safety glass vacuum laminating bags, solar vacuum press laminator, hot press laminator, card press laminator and others application etc.



Specifications:

material: 100% virgin HTV silicone material

grade: industrial grade, food grade, medical grade, FDA grade with postcured

quality: high tear resistant, middle tear resistant, general tear resistant

color: translucent, dark red, black, milk white, grey, blue etc.

surface: smooth/smooth, smooth/impression fabric, smooth/sand or double impression fabric

reinforce: insert 1 PLY fiberglass fabric, aramid fabric or wire mesh SS201, SS304, SS316

tensile strength: 7.5-12.0Mpa

hardness: 10, 20, 30, 40, 50, 60, 70, 80+/-5shore A

elongation: 350%-720%

density: 1.25-1.50g/cm3

tear strength: 26-42N/mm

working temperature: -60°C - +260°C(moment 300°C)

thickness: 0.1-50mm

width: 0.1-3.6m

length: 1-50m

standard size:

0.1-1.0mm x 0.5m x 25/50m

0.5-8.0mm x 0.5-1.2m x 10/20m

1.0-30.0mm x 0.5/1.0/1.2/1.5m x 10/20m

1.0-6.0mm x 1.5-3.6m x 10/20/30m

OEM & customized size are agreed

packing in rolls, pallets or crate

Press for Wooden Laminator:

Translucent-grey Germany silicone membrane for "+" and "-" press on wooden PVC vacuum press laminator

Translucent Chinese silicone membrane for "-" press only on wooden PVC vacuum press laminator

Special supply FDA grade silicone sheet with postcure and antistatic silicone sheet with fire-resistant, black color, smooth surface

***When you enquiry, pls confirm the application, color, hardness, size and quantity***





Examination project

Unit

Standard value

Luster



silicon rubber sheets with all kinds of luster, fresh and bright

Hardness

ShoreA

40, 70+/5

Color

-

translucent, red, black, white, grey etc.

Proportion

g/cm3

1.25

Longitudinal strength

Mpa

7.5-12.0

Pulls apart the elongation ratio

%

350-720%

Compression the permanent

deformationTest specimen

Specification:Compression ratio25%,

170°C×24 Hour

%

22

        Tear strength

N/mm

26

Heat resistance

°C

-60-260(Extreme temperatures)

Linear shrinkage rate

%

3.6

Rebound rate

%

66

Insulation intensity

Kv/mm

18

Brittle temperature

°C

-25°CThe test specimen does not have the change

100%modulus at a definite elongation

Mpa

5.1
