High Tensile Strength Food Grade Platinum Cured Silicone Tube Extrusion and Hose
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ROHS/FCC/SGS |
| Model Number | 3A1003 |
| Minimum Order Quantity | 20kgs |
| Price | USD4.00-7.30 per kg |
| Packaging Details | packing in rolls, cartons and pallets |
| Delivery Time | 10-20 working days after received your payment |
| Payment Terms | T/T,L/C,Paypal,Western Union |
| Supply Ability | 100000kgs per month |
Product Details
| Material | Food Grade Silicone Rubber | Color | Transparent |
|---|---|---|---|
| Tensile Strength | 7.5Mpa | Hardness | Shore A 50-80 |
| Elongation | 350% | Density | 1.25-1.35 G/cm³ |
| Working Temperature | -60°C - +260°C(moment 300°C) | Keyword | Silicone Profile |
| Rohs Compliant | Yes | Outer Diameter | 3mm-60mm |
| Quality | High Tear Resistant | Diameter | 1mm-50mm |
| Rohs Compliance | Yes | Flexibility | Flexible |
| Cured | Platinum Cured | Inner Diameter | 1mm-50mm |
| Size | Build Mould As Per The Buyer's Drawing | Application | Medical, Food And Beverage, Industrial |
| Highlight | flexible silicone tubing,silicone rubber pipe |
||
Product Description
High Tensile Strength Clear Silicone Tube Extrusion Without Smell / Silicone Water Hose
silicone hose, silicone tube, silicone tubing, silicone pipe, food grade without smell
Our silicone hose is extruded using specialized equipment with high-quality silicone rubber, manufactured to specific inside and outside diameter requirements. Featuring high tensile strength, excellent flexibility, strong anti-pull properties, and a wide range of hardness options, these tubes offer superior aging resistance, ozone resistance, heat resistance, insulation properties, and resistance to fuel oil and lubricants.
Designed to operate in air, water, or oil media at temperatures ranging from -60°C to +250°C. Our industrial grade silicone hose is manufactured with standard extruded silicone and vulcanized with imported peroxide, ensuring no odor. Food grade silicone hose is produced using transparent fumed silicone with platinum vulcanization, making it non-toxic and tasteless. Medical grade silicone hose utilizes medical grade transparent fumed silicone with platinum vulcanization and holds FDA and LFGB certifications.
Ideal applications include corona rollers or transferring water, air, oil, and other media.
Technical Specifications
| Material | 100% Virgin Silicone |
|---|---|
| Quality | Food Grade |
| Color Options | Transparent, Translucent, Dark Red, Black, Milk White, Blue, Grey, etc. |
| Surface | Smooth/Smooth |
| Fiber Reinforced | Available |
| Tensile Strength | 7-8 MPa |
| Hardness | 40, 50, 60, 70, 80 ±5 Shore A |
| Elongation | 350% |
| Density | 1.2 ±0.05 g/cm³ |
| Tear Strength | 26 N/mm |
| Working Temperature | -60°C to +250°C |
Standard Sizes
| Dimensions (ID x OD) | Package Quantity |
|---|---|
| Ø2mm x Ø4mm | 5-10 kgs |
| Ø3mm x Ø5mm | 5-10 kgs |
| Ø4mm x Ø6mm | 5-10 kgs |
| Ø5mm x Ø8mm | 5-10 kgs |
| Ø6mm x Ø9mm | 5-10 kgs |
| Ø7mm x Ø10mm | 5-10 kgs |
| Ø8mm x Ø10mm | 5-10 kgs |
| Ø9mm x Ø12mm | 5-10 kgs |
| Ø10mm x Ø14mm | 5-10 kgs |
| Ø12mm x Ø16mm | 5-10 kgs |
| Ø14mm x Ø18mm | 5-10 kgs |
| Ø20mm x Ø30mm | 5-10 kgs |
| Ø30mm x Ø40mm | 5-10 kgs |
| Ø40mm x Ø50mm | 5-10 kgs |
Custom Sizes Available: OEM sizes are available upon request.
Product Images
