Industrial Silicone Rubber Sheet 1-6mm Thick for PVC Laminator
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ROHS/FCC/SGS |
| Model Number | 3A1001 |
| Minimum Order Quantity | 200kgs |
| Price | USD3-15.00/kg |
| Packaging Details | packing in rolls, bags and pallets |
| Delivery Time | 7-15days after receive the buyer's payment |
| Payment Terms | T/T,L/C,Paypal,Western Union,D/P |
| Supply Ability | 100000kgs per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Silicone Rubber | Grade | Industrial Grade |
|---|---|---|---|
| Quality | Superior | Surface | Smooth, Sand Or Impression Fabric |
| Color | Transparent, Grey | Tensile Strength | 7.5 Or 12Mpa |
| Hardness | 40, 50+/-5shore A | Elongation | 400%-720% |
| Density | 1.25g/cm3 | Tear Strength | 26-42N/mm |
| Working Temperature | -60°C - +260°C(moment 300°C) | Thickness | 1-6mm |
| Width | 1.5-3.6m | Length | 1-20m |
| Cured | Platinum Cured | Adhesive Backing | Yes, Custom |
| Uniform Heating | Maximum 220 Degree C | Warranty | Limited, Lifetime |
| Rubber Name | Silicon Sheet | Lead Time | 7-15 Days |
| Fda Compliance | Yes | Specific Gravity | 1.25-1.50g/cm3 |
| Highlight | silicone gasket sheet,flexible rubber sheet |
||
Product Description
Silicone Rubber Sheet for Wooden PVC Laminator
100% Virgin Material Resistant to High Temperature and Tear
High quality silicone rubber membrane/sheet/roll specially designed for wooden PVC laminating press applications. Made from premium virgin Germany silicone rubber with exceptional durability and performance characteristics.
Key Features
- Excellent high temperature resistance (working temp 230-260°C, momentary max 300°C)
- Superior elasticity and rebound properties
- Non-stick, inert surface without viscosity
- Resistant to oils, solvents, and aging
- Flame retardant and non-toxic
- High tear resistance for demanding applications
Product Specifications
| Product Number | 3A1001-WSO300 Series |
|---|---|
| Material | 100% virgin Germany silicone rubber |
| Application | Special for wooden PVC laminator |
| Color | Light grey |
| Surface | Smooth/smooth |
| Tensile Strength | 12Mpa |
| Hardness | 40±5 Shore A |
| Elongation at Break | 720% |
| Density | 1.3g/cm³ |
| Tear Strength | 42N/mm |
| Working Temperature | -60°C to +260°C |
| Available Dimensions |
Thickness: 1-6mm Width: 1.5-3.6m Length: 10-20m |
Ordering Information
| Minimum Order Quantity | 4 rolls |
|---|---|
| Packing | Rolls wrapped in plastic film |
| Payment Terms | T/T in advance |
| Delivery Time | 10-20 days after receiving payment |
Note: All specifications are typical values and may vary slightly. For exact requirements, please contact our technical team.
