High Temperature Resistance Close Cell Silicone Foam Sheet 1.5-50mm Thick Industrial Grade
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ISO9001 |
| Model Number | 3A1002 |
| Minimum Order Quantity | 100kgs/month |
| Price | USD6.00-10.00/kg |
| Packaging Details | packing in rolls, bags and pallets |
| Delivery Time | 7-15days after receive the buyer's payment |
| Payment Terms | L/C,D/P,T/T,Western Union |
| Supply Ability | 100000kgs/month |
Product Details
| Commodity | Silicone Sponge Sheet | Name | Red Color 50mm Thick High Temperature Foam Sheet With Close Cell |
|---|---|---|---|
| Cell | Close Cell | Surface | Impression Fabric |
| Quality | Industrial Grade | Hardness | 10-40shore A |
| Density | 0.4-1.0g/cm3 | Thickness | 1.5-50mm |
| Width | 0.1-1.5m | Length | 0.1-10m |
| Grade | Industrial Grade | Processing Service | Moulding |
| Elogation | ＞100% | Uv Resistance | Good |
| Logo | Customizable Logo | Usage | Widely Used |
| Style | Mechanical Seal | Feature | Sealing Performance |
| Ply Material | Aramid Fabric Or Glassfiber Fabric | Working Temperaturing | -60℃-+260℃ |
| Warranty | Limited, Lifetime | Custom Service | Is Available |
| Highlight | 50mm thick high temperature foam sheet,close cell high temperature foam sheet,50mm thick silicone foam rubber sheet |
||
Product Description
Red Color 1.5-50mm Thick High Temperature Silicone Foam Sheet With Close Cell
Red Color Silicone Sponge Sheet, Silicone Foam Sheet With Close Cell
This silicone foam sheet is made from extremely resilient silicone, displaying excellent resistance to heat, weathering, ozone and a wide range of chemicals. It is impervious to UV lighting, non-toxic, chemically inert and retains its properties within -60°C to 230°C.
Product Features
- Rugged: When silicone is required, silicone sponge parts offer better toughness compared to silicone foam products
- Wide operating temperature: Temperature range of -58°F to 500°F (-50°C to 220°C)
- Water sealing: Closed cell structure allows for good water sealing with relatively low compressive forces
- Compression set resistance: Excellent compression set resistance (ability to rebound to original thickness), especially at higher temperatures
- UV and ozone resistance: Excellent UV and ozone resistance due to inorganic backbone, providing long-term performance
Product Applications
- Engineering machinery, ironing table, pressing machine
- Electrical and electronic devices, computer, printers
- Automotive, aerospace, garment, and energy industries
- Furnaces, heaters, kitchen utensils, flues, gas appliances
Specifications
| Parameter | Specification |
|---|---|
| Material | Virgin silicone sponge, silicone foam |
| Cell Structure | Closed cell |
| Color | Dark red, white, grey, black, beige, brown, blue etc. |
| Surface | Double impression fabric, smooth |
| Tensile Strength | 100-200 PSI |
| Hardness | 10, 15, 20, 25, 30, 35, 40+/-5 shore A (currently 20-25 shore A) |
| Elongation | 100% |
| Density | 0.48-1.00 g/cm³ |
| Working Temperature | -60°C to +220°C (momentary 260°C) |
| Thickness | 1.5-50 mm |
| Width | 0.1-1.5 m (maximum 1.5m @ more than 5mm thickness) |
| Length | 0.1-10 m |
Standard Sizes
- 1.5-50mm * 1.0m * 10m
- 1.5-50mm * 1.2m * 10m
- 5.0-50mm * 1.5m * 10m
Hardness & Density Correlation
- 10 shore A, density 0.48-0.50 g/cm³
- 15 shore A, density 0.50-0.55 g/cm³
- 20-25 shore A, density 0.60-0.65 g/cm³
- 25-30 shore A, density 0.65 g/cm³
- 30-40 shore A, density 1.00 g/cm³
Additional Information
- OEM & customized sizes available
- Packing in cartons, rolls, pallets or crates
- Backing adhesive available with Chinese general glue or USA 3M glue
- Perforated silicone sponge sheet: 6, 8, 10mm * 0.9m * 1.8m in red, beige, white color
- Custom sizes for silicone sponge extrusion, profile, and stripe
For more data & information, please email to: sales@3Arubber.com
When you enquire, please confirm the hardness, color, size and quantity
