Food Grade High Temperature Resistant Silicone Rubber Sheet and Membrane with Customizable Size
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ISO9001 |
| Model Number | 3A1001 |
| Minimum Order Quantity | 100kgs |
| Price | USD10.00/kg |
| Packaging Details | packing in rolls, bags and pallets |
| Delivery Time | 7-15days after receive the buyer's payment |
| Payment Terms | L/C,D/P,T/T,Western Union |
| Supply Ability | 100000kgs/month |
Product Details
| Material | Silicone Rubber | Color | Translucent, Grey, Black, Blue |
|---|---|---|---|
| Surface | Smooth, Matt, Impression Fabric | Tensile Strenth | 7.5-12Mpa |
| Hardness | 40-80 Shore A | Elongation | 350%-720% |
| Density | 1.25g/cm3 | Tear Strength | 26-42N/mm |
| Thickness | 1mm-6mm | Width | 1.5-3.6m |
| Length | 10-20m | Size | Customizd |
| Working Temperature | -60^C ~ +260^C | Uniform Heating | Maximum 220 Degree C |
| Surface Finish | Smooth/Textured | Port | Shanghai Port And Others |
| Production | Mold Compression | Tensible Strengh | 7-12Mpa |
| Logo | Custom Logo | Top | Impression Fabric |
| Customization | Size, Color, Printing | Weather Resistance | Excellent |
| Elogation | 250-400% | Quality | Food Grade Without Smell |
| Standard Width | 0.5m,1.0m ,1.2m And 1.5m | Certifications | FDA, RoHS, REACH |
| Proof Voltage | 15KV-50KV | ||
| Highlight | Silicone Membrane Rubber Sheet,Special Silicone Rubber Sheet,Wooden Door Silicone Rubber Sheet |
||
Product Description
Special Silicone Rubber Sheet for Wooden Door, Silicone Rubber Sheet, Silicone Roll, Silicone Membrane
Silicone Sheet, Silicone Roll, Silicone Membrane, Silicone Diaphragm, Silicone Rubber Sheet Special for Wooden Door
Our silicone sheets, membranes, and rolls are manufactured using high-quality silicone material on specialized rotocure vulcanizers or plain press vulcanizers, tailored to meet specific customer size requirements. We offer various production capabilities:
- General silicone sheets (0.5-12mm x 0.5-1.5m x 1-10m) produced on 4-roller rotocure vulcanizers
- Super wide and special silicone sheets (1.0-8.0mm x 1.5-3.8m x 10-20m) produced on 2-roller rotocure vulcanizers
- Super thin and special silicone sheets (0.1-1.0mm x 0.3-1.0m x 25-50m) produced on special oven road vulcanizers
- Super thick silicone sheets produced on plain press vulcanizers
Through advanced management, innovative techniques, and strict quality control using premium silicone materials and vulcanizer machinery, we've resolved common manufacturing challenges including surface smoothness issues, thickness tolerance in rotocure vulcanizers, and width/length restrictions with visible joints in press vulcanizing machines. Our products feature seamless construction with infinite length capabilities.
We operate super-wide drum-type vulcanizing presses with 4000mm width capacity, producing maximum 3800mm width products that are completely seamless and joint-free.
Our high-quality silicone rubber offers excellent performance characteristics including anti-aging properties, ozone resistance, heat resistance (-60°C to +260°C, momentary maximum 300°C), electrical insulation, oil resistance, solvent resistance, corrosion resistance, non-toxic and odor-free composition, and pollution-free operation. The material maintains high stability and reliability with non-sticky surface properties.
Applications include punching various rubber seals and gaskets, plus specialized uses for wooden PVC vacuum laminators, steel door vacuum laminators, safety glass vacuum laminating bags, solar photovoltaic module vacuum laminators, hot press laminators, card press laminators, and other industrial applications.
Specifications
| Parameter | Specifications |
|---|---|
| Material | 100% virgin HTV silicone material |
| Grade | Industrial grade, food grade, medical grade, FDA grade with postcured |
| Quality | High tear resistant, middle tear resistant, general tear resistant |
| Color | Translucent, dark red, black, milk white, grey, blue, etc. |
| Surface | Smooth/smooth, smooth/impression fabric, smooth/sand or double impression fabric |
| Reinforcement | Insert 1 PLY fiberglass fabric, aramid fabric or wire mesh SS201, SS304, SS316 |
| Tensile Strength | 7.5-12.0 MPa |
| Hardness | 10, 20, 30, 40, 50, 60, 70, 80 ±5 Shore A |
| Elongation | 350%-720% |
| Density | 1.25-1.50 g/cm³ |
| Tear Strength | 26-42 N/mm |
| Working Temperature | -60°C to +260°C (momentary 300°C) |
| Thickness | 0.1-50 mm |
| Width | 0.1-3.6 m |
| Length | 1-50 m |
Standard Sizes
- 0.1-1.0mm x 0.3-1.0m x 25-50m
- 0.5-12.0mm x 0.5-1.5m x 10-20m
- 10.0-50.0mm x 0.5/1.0/1.2/1.5m x 1-20m
- 1.0-8.0mm x 1.5-3.8m x 10-20m
OEM and customized sizes available upon agreement. Packing options include rolls, pallets, or crates.
Special Silicone Membrane Applications
- Wooden PVC Vacuum Laminator: Grey silicone membrane, 9.8 MPa, 40 Shore A, 750%, 42 N/mm (Germany silicone) for "+" and "-" press applications
- Wooden PVC Vacuum Laminator: Translucent silicone membrane, 7.5 MPa, 50 Shore A, 400%, 26 N/mm (Chinese silicone) for "-" press only applications
- Solar Vacuum Laminator: Grey silicone membrane, 12.0 MPa, 60-70 Shore A, 350%, 45 N/mm (Germany silicone) for photovoltaic modules
- Glass Vacuum Bag & Laminator: Sky blue silicone membrane, 7.5 MPa, 50 Shore A, 350%, 26 N/mm (Chinese silicone) for safety glass
- Glass Vacuum Bag & Laminator: Dark blue silicone membrane, 8.0 MPa, 57 Shore A, 450%, 30 N/mm (Chinese silicone) for safety glass
We also specialize in FDA grade silicone sheets with postcure treatment and antistatic silicone sheets with fire-resistant properties in black color with smooth surface. Additional offerings include black antistatic silicone sheet backing with or without 3M adhesive in thicknesses of 0.2, 0.5, 0.8, 1.0, 1.2, 1.5, 2.0, and 3.0mm.
For detailed technical data and additional information, please contact:
Email: sales@3Arubber.com
When making an enquiry, please specify: hardness, color, size, and quantity requirements.
