0.1-0.8mm Silicone Rubber Sheet 50m Roll, 7.5Mpa Tensile Strength

  • 0.1-0.8mm Silicone Rubber Sheet 50m Roll, 7.5Mpa Tensile Strength
  • 0.1-0.8mm Silicone Rubber Sheet 50m Roll, 7.5Mpa Tensile Strength
  • 0.1-0.8mm Silicone Rubber Sheet 50m Roll, 7.5Mpa Tensile Strength
  • 0.1-0.8mm Silicone Rubber Sheet 50m Roll, 7.5Mpa Tensile Strength
  • 0.1-0.8mm Silicone Rubber Sheet 50m Roll, 7.5Mpa Tensile Strength
  • 0.1-0.8mm Silicone Rubber Sheet 50m Roll, 7.5Mpa Tensile Strength
Place of Origin China
Brand Name 3A Rubber
Certification ISO9001
Model Number 3A1001
Minimum Order Quantity 200kgs
Price USD3-6.20/kg
Packaging Details Packing in rolls and pallets
Delivery Time 7-15days after receive the buyer's payment
Payment Terms L/C,D/P,T/T,Western Union,MoneyGram
Supply Ability 100000kgs/month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Silicone Rubber Quality Food Grade
Surface Smooth Tensile Strength 7.5Mpa
Hardness 10-75shore A Elongation 350%
Density 1.25g/cm3 Tear Strength 26-42N/mm
Aging Resistance Excellent Grade Food Grade Without Smell
Top Impression Fabric Width 1m/1.2m/1.5m/2m
Working Temp -40^C ~ +260^C Heater Width Maximum 48 Inches(1.2 M)
Lead Time 20-30 Days Top Layer 10^7-10^9Ω
Tearstrength 25N/mm Rubber Name Rubber Pad
Ply Material Aramid Fabric Or Glassfiber Fabric Working Temperaturing -60℃-+260℃
Cable Custom Model No TS-RSS01
Highlight

0.5m Silicone Rubber Sheet

,

0.8mm Silicone Rubber Sheet
Leave a Message
Product Description
0.1-0.8mm x 0.5m x 50m Silicone Rubber Sheet, Silicone Roll, Silicone Membrane for High-Temperature Resistance

Our premium silicone sheets, membranes, and rolls are manufactured using high-quality silicone material on specialized vulcanizing equipment to meet exact customer specifications. Available in various thicknesses, widths, and lengths to suit diverse industrial applications.

Manufacturing Process
  • Standard silicone sheets (0.5-12mm x 0.5-1.5m x 1-10m) produced on 4-roller rotocure vulcanizers
  • Extra-wide specialty sheets (1.0-8.0mm x 1.5-3.8m x 10-20m) produced on 2-roller rotocure vulcanizers
  • Ultra-thin specialty sheets (0.1-1.0mm x 0.3-1.0m x 25-50m) produced on special oven road vulcanizers
  • Extra-thick sheets produced on plain press vulcanizers
Key Features
  • Anti-aging and ozone resistant
  • Excellent heat resistance (-60°C to +260°C, momentary 300°C)
  • Electrical insulation properties
  • Oil, solvent, and corrosion resistant
  • Non-toxic, odorless, and pollution-free
  • High stability and reliability with non-stick surface
Technical Specifications
Property Specification
Material 100% virgin HTV silicone material
Grades Available Industrial, food, medical, FDA (with postcure)
Colors Translucent, dark red, black, milk white, grey, blue
Surface Options Smooth/smooth, smooth/impression fabric, smooth/sand or double impression fabric
Reinforcement Options Fiberglass fabric, aramid fabric, or wire mesh SS201, SS304, SS316
Tensile Strength 7.5-12.0Mpa
Hardness 10-80±5 Shore A
Elongation 350%-720%
Density 1.25-1.50g/cm³
Tear Strength 26-42N/mm
Standard Sizes
  • 0.1-1.0mm x 0.3-1.0m x 25-50m
  • 0.5-12.0mm x 0.5-1.5m x 10-20m
  • 10.0-50.0mm x 0.5/1.0/1.2/1.5m x 1-20m
  • 1.0-8.0mm x 1.5-3.8m x 10-20m

Custom sizes available upon request.

Specialty Silicone Membranes
  • Grey membrane (Germany silicone) for wooden PVC vacuum laminators
  • Translucent membrane (Chinese silicone) for wooden PVC vacuum laminators
  • Grey membrane (Germany silicone) for solar photovoltaic module laminators
  • Sky blue/dark blue membranes (Chinese silicone) for safety glass vacuum bags
  • FDA grade and antistatic silicone sheets available

For more information:
Email: sales@3Arubber.com

When inquiring, please specify hardness, color, size, and quantity requirements.
