0.1-0.8mm High-Temperature Resistance Food Grade Silicone Rubber Sheet with Excellent Aging Resistance
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ISO9001 |
| Model Number | 3A1001 |
| Minimum Order Quantity | 200kgs |
| Price | USD3-6.20/kg |
| Packaging Details | Packing in rolls and pallets |
| Delivery Time | 7-15days after receive the buyer's payment |
| Payment Terms | L/C,D/P,T/T,Western Union |
| Supply Ability | 100000kgs/month |
Product Details
| Material | Silicone Rubber | Quality | Food Grade |
|---|---|---|---|
| Surface | Smooth | Tensile Strength | 7.5Mpa |
| Hardness | 10-75shore A | Elongation | 350% |
| Density | 1.25g/cm3 | Tear Strength | 26-42N/mm |
| Aging Resistance | Excellent | Grade | Food Grade Without Smell |
| Top | Impression Fabric | Width | 1m/1.2m/1.5m/2m |
| Working Temp | -40^C ~ +260^C | Heater Width | Maximum 48 Inches(1.2 M) |
| Lead Time | 20-30 Days | Top Layer | 10^7-10^9Ω |
| Tearstrength | 25N/mm | Rubber Name | Rubber Pad |
| Ply Material | Aramid Fabric Or Glassfiber Fabric | Working Temperaturing | -60℃-+260℃ |
| Cable | Custom | Model No | TS-RSS01 |
| Highlight | 0.5m Silicone Rubber Sheet,0.8mm Silicone Rubber Sheet |
||
Product Description
0.1-0.8mm x 0.5m x 50m Silicone Rubber Sheet, Silicone Roll, Silicone Membrane for High-Temperature Resistance
Our silicone sheets, membranes, and rolls are manufactured using high-quality silicone material on specialized rotocure vulcanizers or plain press vulcanizers, tailored to meet specific customer size requirements. We utilize advanced management, innovative techniques, and strict quality control with premium silicone materials and vulcanizer machinery to ensure superior product quality.
Manufacturing Capabilities
- General silicone sheet (0.5-12mm x 0.5-1.5m x 1-10m) produced on 4-roller rotocure vulcanizers
- Super wide and special silicone sheet (1.0-8.0mm x 1.5-3.8m x 10-20m) produced on 2-roller rotocure vulcanizers
- Super thin and special silicone sheet (0.1-1.0mm x 0.3-1.0m x 25-50m) produced on special oven road vulcanizers
- Super thick silicone sheet produced on plain press vulcanizers
Our advanced manufacturing processes overcome traditional limitations, delivering seamless products without joints and with virtually infinite length. We feature super-wide drum-type vulcanizing presses with 4000mm width capacity, producing maximum 3800mm width seamless products without joints.
Product Specifications
| Material | 100% virgin HTV silicone material |
| Grade | Industrial grade, food grade, medical grade, FDA grade with postcured |
| Quality | High tear resistant, middle tear resistant, general tear resistant |
| Color | Translucent, dark red, black, milk white, grey, blue, etc. |
| Surface | Smooth/smooth, smooth/impression fabric, smooth/sand or double impression fabric |
| Reinforce | Insert 1 PLY fiberglass fabric, aramid fabric or wire mesh SS201, SS304, SS316 |
| Tensile Strength | 7.5-12.0 MPa |
| Hardness | 10, 20, 30, 40, 50, 60, 70, 80 ±5 Shore A |
| Elongation | 350%-720% |
| Density | 1.25-1.50 g/cm³ |
| Tear Strength | 26-42 N/mm |
| Working Temperature | -60°C to +260°C (momentary maximum 300°C) |
| Thickness | 0.1-50 mm |
| Width | 0.1-3.6 m |
| Length | 1-50 m |
Standard Sizes
- 0.1-1.0mm x 0.3-1.0m x 25-50m
- 0.5-12.0mm x 0.5-1.5m x 10-20m
- 10.0-50.0mm x 0.5/1.0/1.2/1.5m x 1-20m
- 1.0-8.0mm x 1.5-3.8m x 10-20m
OEM and customized sizes available upon agreement. Packing available in rolls, pallets, or crates.
Special Silicone Membranes
- Grey, 9.8 MPa, 40 Shore A, 750%, 42 N/mm Germany silicone for "+" and "-" press on wooden PVC vacuum laminator
- Translucent, 7.5 MPa, 50 Shore A, 400%, 26 N/mm Chinese silicone for "-" press only on wooden PVC vacuum laminator
- Grey, 12.0 MPa, 60-70 Shore A, 350%, 45 N/mm Germany silicone for photovoltaic module on solar vacuum laminator
- Sky blue, 7.5 MPa, 50 Shore A, 350%, 26 N/mm Chinese silicone for safety glass on glass vacuum bag and laminator
- Dark blue, 8.0 MPa, 57 Shore A, 450%, 30 N/mm Chinese silicone for safety glass on glass vacuum bag and laminator
Special supply available for FDA grade silicone sheet with postcure and antistatic silicone sheet with fire-resistant properties (black color, smooth surface). Also available: black antistatic silicone sheet backing with or without adhesive 3M, thicknesses 0.2, 0.5, 0.8, 1.0, 1.2, 1.5, 2.0, 3.0mm.
Applications
High-quality silicone rubber with excellent anti-aging, ozone resistance, heat resistance, electric insulation, oil resistance, solvent resistance, corrosion resistance, non-toxic and odorless properties. Working in air, water, oil and other media at temperatures from -60°C to +260°C (momentary maximum 300°C) with high stability, reliability and non-sticky surface. Suitable for punching various rubber seals, rubber gaskets, and specialized applications including wooden PVC vacuum laminators, steel door vacuum laminators, safety glass vacuum laminating bags, solar photovoltaic module vacuum laminators, hot press laminators, card press laminators and more.
Contact Information
For more data and information, please email to: sales@3Arubber.com
When you enquire, please confirm the hardness, color, size and quantity requirements.
