Food Grade Silicone Rubber Sheet 1m-2m Width 40-80 Shore A

  • Food Grade Silicone Rubber Sheet 1m-2m Width 40-80 Shore A
  • Food Grade Silicone Rubber Sheet 1m-2m Width 40-80 Shore A
  • Food Grade Silicone Rubber Sheet 1m-2m Width 40-80 Shore A
  • Food Grade Silicone Rubber Sheet 1m-2m Width 40-80 Shore A
  • Food Grade Silicone Rubber Sheet 1m-2m Width 40-80 Shore A
  • Food Grade Silicone Rubber Sheet 1m-2m Width 40-80 Shore A
Place of Origin China
Brand Name 3A Rubber
Certification ISO9001
Model Number 3A1001
Minimum Order Quantity 200kgs
Price USD3-15.00/kg
Packaging Details packing in rolls, bags and pallets
Delivery Time 7-15days after receive the buyer's payment
Payment Terms L/C,D/P,T/T,Western Union,MoneyGram
Supply Ability 100000kgs/month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Virgin Silicone Quality Food Grade
Surface Smooth Or Textured Tensile Strength 7-12 MPa
Hardness 40-80 Shore A Elongation 350%
Density 1.25-1.50 G/cm3 Tear Strength 26-42N/mm
Specific Gravity 1.2-1.25g/cm3 Flammability UL94-V0
Working Temperaturing -60℃-+260℃ Compression Set ≤25%
Finish Smooth Or Textured Finish Reinforce Insert 1 Ply Fabric
Width 1m-2m Origin China
Elongation At Break 300-600%
Highlight

Silicone Membrane Sheet

,

Food Processing Silicone Sheet

,

Food Grade Silicone Sheet
Leave a Message
Product Description
Food Grade Silicone Rubber Sheet, Silicone Roll, Silicone Membrane
High-quality silicone sheets, membranes, and rolls manufactured using premium silicone material on specialized vulcanizing equipment to meet various size requirements.
Production Capabilities
  • Standard sheets (0.5-12mm thickness, 0.5-1.5m width, 1-10m length) produced on 4-roller rotocure vulcanizers
  • Extra-wide sheets (1.0-8.0mm thickness, 1.5-3.8m width, 10-20m length) on 2-roller rotocure vulcanizers
  • Ultra-thin sheets (0.1-1.0mm thickness, 0.3-1.0m width, 25-50m length) on special oven road vulcanizers
  • Thick sheets produced on plain press vulcanizers
Key Features
  • Seamless production with maximum width of 3800mm
  • Excellent anti-aging, ozone resistance, and heat resistance
  • Superior electrical insulation and chemical resistance
  • Non-toxic, tasteless, and pollution-free
  • Operating temperature range: -60°C to +260°C (momentary 300°C)
  • Stable performance in air, water, and oil environments
Technical Specifications
Material 100% virgin HTV silicone material
Grades Available Industrial grade, food grade, medical grade, FDA grade (post-cured)
Quality Options High tear resistant, medium tear resistant, general tear resistant
Color Options Translucent, dark red, black, milk white, grey, blue, etc.
Surface Finishes Smooth/smooth, smooth/impression fabric, smooth/sand or double impression fabric
Reinforcement Options Fiberglass fabric, aramid fabric, or wire mesh (SS201, SS304, SS316)
Tensile Strength 7.5-12.0 MPa
Hardness 10-80 Shore A (±5)
Elongation 350%-720%
Density 1.25-1.50 g/cm³
Tear Strength 26-42 N/mm
Standard Sizes
  • 0.1-1.0mm × 0.3-1.0m × 25-50m
  • 0.5-12.0mm × 0.5-1.5m × 10-20m
  • 10.0-50.0mm × 0.5/1.0/1.2/1.5m × 1-20m
  • 1.0-8.0mm × 1.5-3.8m × 10-20m
  • Custom sizes available upon request
Special Silicone Membranes
  • Grey membrane (9.8MPa, 40 Shore A) for wooden PVC vacuum laminators
  • Translucent membrane (7.5MPa, 50 Shore A) for wooden PVC vacuum laminators
  • Grey membrane (12.0MPa, 60-70 Shore A) for solar photovoltaic modules
  • Sky blue/dark blue membranes for safety glass applications
  • FDA grade and antistatic silicone sheets available
Food Grade Silicone Rubber Sheet 1m-2m Width 40-80 Shore A 0 Food Grade Silicone Rubber Sheet 1m-2m Width 40-80 Shore A 1 Food Grade Silicone Rubber Sheet 1m-2m Width 40-80 Shore A 2 Food Grade Silicone Rubber Sheet 1m-2m Width 40-80 Shore A 3
For more information:
Email: sales@3Arubber.com
When inquiring, please specify hardness, color, size, and quantity requirements.
