Food Grade Silicone Rubber Sheet 0.1-50mm Thickness Heat Resistant 220°C
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ISO9001 |
| Model Number | 3A1002 |
| Minimum Order Quantity | 100kgs |
| Price | USD3-15.00/kg |
| Packaging Details | packing in rolls, bags and pallets |
| Delivery Time | 7-15days after receive the buyer's payment |
| Payment Terms | L/C,,D/P,T/T,Western Union,MoneyGram,Alipay,Wechat,Paypal |
| Supply Ability | 100000kgs/month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Plastic+silicone+PET | Quality | Food Grade |
|---|---|---|---|
| Color | Translucent, Black, White, Red | Surface | Smooth Or Matt |
| Tensile Strength | 7.0Mpa | Hardness | 10-70shore A |
| Elongation | 300-600% | Density | 1.25g/cm3 |
| Thickness | 0.1mm-50mm | Width | 0.3-0.5mm |
| Length | 1m-50m | Packing | In Rolls And Pallets |
| Feature | Anti-slip, Heat Resistant | Uniform Heating | Maximum 220 Degree C |
| Aging Resistance | Excellent | Temperature | 170-250℃ |
| Warranty | Limited, Lifetime | Adhesive Backing | Yes, Custom |
| Custom Service | Is Available | Flammability | UL94-V0 |
| Highlight | 7.0Mpa Adhesive Backed Silicone Rubber Sheet,50m Adhesive Backed Silicone Rubber Sheet,50m Heat Resistant Silicone Rubber Sheet |
||
Product Description
Silicone Rubber Sheet Silicone Roll for Anti-Aging and Chemical Resistance
Product Description
Silicone Sheet, Silicone Roll Size 0.1-1.0mm × 0.3-0.5m × 50m
Our premium silicone sheets, membranes, and rolls are manufactured using high-quality silicone material on specialized vulcanizing equipment tailored to customer requirements. We utilize advanced production techniques and strict quality control to deliver products with superior surface smoothness and precise thickness tolerance.
Key Features
- Available in industrial, food, medical, and FDA grades with post-cure options
- Excellent anti-aging, ozone resistance, and heat-resistant properties
- Superior electrical insulation and chemical resistance
- Non-toxic, tasteless, and pollution-free
- Operational temperature range: -60°C to +260°C (momentary peak at 300°C)
- High stability and reliability with non-stick surface
- Available in seamless rolls up to 3800mm width without joints
Technical Specifications
| Material | 100% virgin HTV silicone material |
|---|---|
| Grades Available | Industrial grade, food grade, medical grade, FDA grade with postcured |
| Quality Options | High tear resistant, middle tear resistant, general tear resistant |
| Color Options | Translucent, dark red, black, milk white, grey, blue, etc. |
| Surface Finish | Smooth/smooth, smooth/impression fabric, smooth/sand or double impression fabric |
| Reinforcement Options | Insert 1 PLY fiberglass fabric, aramid fabric or wire mesh SS201, SS304, SS316 |
| Tensile Strength | 7.5-12.0Mpa |
| Hardness | 10, 20, 30, 40, 50, 60, 70, 80+/-5 shore A |
| Elongation | 350%-720% |
| Density | 1.25-1.50g/cm³ |
| Tear Strength | 26-42N/mm |
| Thickness Range | 0.1-50mm |
| Width Range | 0.1-3.6m |
| Length Range | 1-50m |
Standard Sizes
- 0.1-1.0mm × 0.5m × 25/50m
- 0.5-10.0mm × 0.5-1.2m × 10/20m
- 1.0-30.0mm × 0.5/1.0/1.2/1.5m × 10/20m
- 1.0-8.0mm × 1.5-3.8m × 10/20/30m
- Custom sizes available upon request
Special Silicone Membranes
- Light grey German silicone for vacuum press laminators (9.8Mpa, 40 shore A)
- Translucent Chinese silicone for vacuum press laminators (7.5Mpa, 50 shore A)
- Dark grey German silicone for solar vacuum laminators (12.0Mpa, 60-70 shore A)
- Sky blue Chinese silicone for safety glass applications (7.5Mpa, 50 shore A)
- Dark blue Chinese silicone for glass vacuum applications (8.0Mpa, 57 shore A)
Specialty Products
- FDA grade silicone sheets with post-cure
- Antistatic silicone sheets with fire-resistant properties
- Black antistatic silicone sheets with or without 3M adhesive (0.2-3.0mm thickness)
Note: When making an inquiry, please specify your application requirements, desired color, hardness, dimensions, and quantity for accurate quotation.
