Heat Resistance Food Grade PTFE Mesh 10 x 10mm , PTFE Mesh Conveyor Belt

Place of Origin China
Brand Name 3A Rubber
Certification ROHS/FCC/SGS
Model Number 3A3008
Minimum Order Quantity 1roll
Price negotiation
Packaging Details Packed in rolls
Delivery Time 10 working days after received your payment
Payment Terms T/T, L/C, Paypal, Western Union
Supply Ability 10000kgs per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Glassfiber Coated PTFE Color Brown, Black, Blue
Joint Bullnose Joint,spiral And Clapper Temperature -60 ~ +320°C
Mesh 0.5x1, 1x1, 2x2.5, 4x4, 6x6, 10x10mm Width Maximum 4.0m
Highlight

ptfe conveyor belt

,

PTFE mesh screen

Leave a Message
Product Description

high temperature resistant PTFE open fiberglass mesh , PTFE / PTFE mesh conveyor belt



Specifications

We are the manufacture of PTFE coated fiberglass mesh fabric
and produce of different kinds with various open mesh size.

PTFE coated fiberglass mesh fabric:
We manufacture different kinds with various open mesh size.



Main Features:

1. Heat resistance property---It is able to wok stably between -60oC to 260oC.

2. Excellent non-sticky property---It easier to remove those resins, dopes, oil and other sticky things.

3. Good mechanical property with no distortion and low friction coefficient.



Applications: Being used in paper printing for protecting from the oil and other sticky things. It is widely used in PRINT INDUSTRY as conveyor belt.



Any special requirement, please contact the research department.





PTFE Coated Fiberglass Open Mesh Conveyor Belt



1.  High temperature resistance—It Can continuously work under-140 to 320°C,max resist high temperature up to 360°C.

2.  Permeability—It can avoid wasting heat and improve drying efficiency for it’s permeability.

3.  Chemical resistance—It can resist all most of chemical medicines.

4.  Non Stick—It can easily remove all kinds of adhesives such as resin, paint and chemical

medicine, easy to clean.





Model Mesh Size Material Thickness Weight Temp Resistance Max Width Tensile Strength
1 1x1mm fiberglass 0.5mm 370g/m² -70~320°C 4000mm 310/290N/cm
2 2x2mm fiberglass 0.7mm 450g/m² -70~320°C 4000mm 350/310N/cm
3 4x4mm fiberglass 1.0mm 400g/m² -70~320°C 4000mm 390/320N/cm
4 4x4mm fiberglass 1.0mm 450g/m² -70~320°C 4000mm 390/320N/cm
5 4x4mm fiberglass and kevlar 1.2mm 600g/m² -70~320°C 4000mm 895/370N/cm
6 4x4mm fiberglass 1.0mm 500g/m² -70~320°C 4000mm 395/370N/cm
7 4x4mm Kevlar 1.0mm 500g/m² -70~320°C 4000mm 900/600N/cm
8 4x4mm fiberglass 1.0mm 550g/m² -70~320°C 4000mm 395/370N/cm
9 10x10mm fiberglass 1.2mm 450g/m² -70~320°C 4000mm 360/300N/cm
10 0.5x1mm fiberglass 0.5mm 420g/m² -70~320°C 4000mm 310/290N/cm
11 2x2.5mm fiberglass 0.9mm 600g/m² -70~320°C 3000mm 390/320N/cm





1. Drying machine for non-woven textile, textile printing, silk-prnting and dyeing machine.

2. Shrinking machine for garment fabric, high-frequency and UV dryer.

3. Conveyer belt for hot-air dryer, various of food baking, quick-frozen machines.

4. Oiling machine for paper glazing and waxing, plant engineering.

5. Seperating sheet for hardboard production etc.
