Anti - corrosion unsintered expanded PTFE gasket tape , PTFE gasket tape
Anti-corrosion unsintered expanded PTFE gasket tape
Main Specification of the PTFE tape
|
Width(mm) |
Thickness(mm) |
Length(m) |
Density(g/cm3) |
|
12mm &1/2” |
0.075mm—0.25mm |
5m — 60m |
0.2g/cm3—1.6g/cm3 |
|
15mm |
0.075mm—0.25mm |
5m — 20m |
0.2g/cm3—1.6g/cm3 |
|
19mm &3/4” |
0.075mm—0.25mm |
5m — 60m |
0.2g/cm3—1.6g/cm3 |
|
25mm & 1” |
0.075mm—0.25mm |
5m — 50m |
0.2g/cm3—1.6g/cm3 |
|
Jumbo roll 120mm to 190mm |
0.075mm—0.25mm |
250m — 2000m |
0.2g/cm3—1.6g/cm3 |
Specification tolerance
Width +- 1mm
Thickness +- 0.02mm
Length +- 0.5m
Density +- 0.05g/cm3
Main Properties
|
No |
Project |
Technical indexes |
Remarks |
|
1 |
Heat-resistance |
+370°C |
|
|
2 |
Cold-resistance |
-190°C |
|
|
3 |
High Pressure Resistance |
150~200kg/cm2 |
|
|
4 |
Tensile Strength |
≥8MPA |
Control according to the demand |
|
5 |
Percentage elongation |
≥25% |
|
|
6 |
Residual lubricant |
≤0.5% |
|
Quick Details
Standard or Nonstandard: standard
Style: Mechanical Seal
Material: PTFE
Spool and cover OD: 56mm
Spool and cover ID: 30mm/33mm
Tape Colour: White
Density: 0.25g/cm^3
Width: 12mm-22mm
Length: 10-15m or as your requirement
Thickness: 0.075mm-0.1mm
Color: White or colorful tapes
ptfe PTFE tape,high and low temperature resistance,solvent resistance, acidproof and alkali proof, and
antioxidant performance
1. Professional manufacturer
2. Best Quality and favorable price
3. material stability
4. easier to wrap under any environment
Application:
Clean, quick and highly effective means of sealing threaded pipe fittings in the engineering,chemical
and electrical
100% PTFE tape for pipe fitting.
Advantage:
1. Expanded ptfe tape.
2. High quality best price ptfe thread seal tape.
3. easy for use
4. perfect for pipe, valves
Sample:Customer give us the detail then we can send sample 5 days later.
Delivery time:30days after received deposit.
Payment term: TT,LC,Cash
Trade Term:FOB,CNF,CIF,EXW
