25-55 MPa Polyurethane Sheet with 75-95 Shore A Hardness and Corrosion Resistance for Industrial Applications

  • 25-55 MPa Polyurethane Sheet with 75-95 Shore A Hardness and Corrosion Resistance for Industrial Applications
  • 25-55 MPa Polyurethane Sheet with 75-95 Shore A Hardness and Corrosion Resistance for Industrial Applications
  • 25-55 MPa Polyurethane Sheet with 75-95 Shore A Hardness and Corrosion Resistance for Industrial Applications
  • 25-55 MPa Polyurethane Sheet with 75-95 Shore A Hardness and Corrosion Resistance for Industrial Applications
  • 25-55 MPa Polyurethane Sheet with 75-95 Shore A Hardness and Corrosion Resistance for Industrial Applications
  • 25-55 MPa Polyurethane Sheet with 75-95 Shore A Hardness and Corrosion Resistance for Industrial Applications
  • 25-55 MPa Polyurethane Sheet with 75-95 Shore A Hardness and Corrosion Resistance for Industrial Applications
Place of Origin China
Brand Name 3A Rubber
Certification ROHS/FCC/SGS
Model Number 3A2001
Minimum Order Quantity 100kgs
Price negotiation
Packaging Details Packing in Pallet
Delivery Time 10 working days after received your payment
Payment Terms L/C,T/T,Western Union,MoneyGram,Paypal
Supply Ability 10000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Virgin CPU Of Polyether Or Polyester Color Clear Yellow, Black, Red, Brown, White, Blue, Green Etc.
Surface Smooth/smooth Tensile Strength 25-50Mpa
Elasticity Impact >25% Hardness 75-95shore A
Elongation 400%-600% Density 1.15-1.25g/cm3
Tear Strength 35-155KN/m Akron Abrasion Loss <0.05cm3/1.61km
Highlight

pu coupling

,

rubber coupling
Leave a Message
Product Description
25-55 MPa Polyurethane Sheet Smooth PU Sheet 75-95 Shore A Hardness
High-performance polyurethane sheets manufactured using premium polyester or polyether materials through mould casting or centrifuge rotor processes. These sheets offer exceptional durability and resistance properties for demanding industrial applications.
Key Performance Characteristics
  • Superior chemical, impregnant, ozone, radiation, aging, and hydrolysis resistance
  • High tensile strength with excellent tear, impact, and bend resistance
  • Low compression set for long-term dimensional stability
  • Abrasion resistance 5x greater than natural rubber
  • Oil resistance 3-5x superior to NBR rubber
  • High elasticity (65%) with outstanding compression resistance at elevated temperatures
  • Wide hardness range of 75-95 Shore A
  • Excellent adhesion to metal substrates
Technical Specifications
Material Virgin polyether or polyester
Color Options Transparent, yellow, brown, black, red, and others
Surface Finish Smooth/Smooth
Tensile Strength 25-50 MPa
Elasticity Impact >25%
Hardness 75-95 Shore A
Elongation 400%-600%
Density 1.12-1.25 g/cm³
Tear Strength 35-155 KN/m
Akron Abrasion Loss <0.05 cm³/1.61 km
Compression Set (22h*70°C) <10%
Maximum Working Temperature 120°C
Available Dimensions
Thickness: 0.1-60mm
Width: 10-1500mm
Length: 500-4900mm
Standard Sheet Sizes
0.1-3.0mm × 1.00m × 40-50kgs
0.1-3.0mm × 1.22m × 40-50kgs
0.1-3.0mm × 1.37m × 40-50kgs
2-20mm × 0.3m × 3.0m
2-20mm × 0.6m × 3.0m
2-20mm × 0.4m × 4.0m
2-20mm × 0.5m × 4.0m
2-20mm × 0.6m × 4.0m
2-20mm × 0.8m × 4.0m
2-20mm × 1.0m × 4.0m
2-20mm × 1.2m × 4.0m
2-20mm × 1.5m × 4.9m
10-60mm × 0.3m × 0.3m
10-60mm × 0.4m × 0.4m
10-60mm × 0.5m × 0.5m
10-60mm × 0.6m × 0.6m
10-60mm × 0.5m × 1.0m
10-60mm × 0.6m × 1.2m
10-60mm × 1.0m × 1.0m
10-60mm × 1.0m × 2.0m
Industrial Applications
Military equipment, mining operations, oil field applications, chemical processing, printing machinery, punch presses, paper manufacturing, shoe production, textile spinning, and automotive industries.
Important: When requesting a quotation, please specify material type, color preference, hardness requirement, dimensions, and quantity needed.
