High Tensile Strength PTFE Packing , PTFE Expand Tape for Industrial Seal

1000 rolls
MOQ
negotiation
Price
High Tensile Strength PTFE Packing , PTFE Expand Tape for Industrial Seal
Features Gallery Product Description Request A Quote
Features
Specifications
Material: Pure PTFE Expand
Color: White,yellow,red
Quality: FDA Grade
Density: 0.15-0.5g/cm³
Working Temperature: -150℃-+250℃
Thinkness: 0.075-0.2mm
Width: 3-100mm
Length: 6-50m
High Light:

ptfe packing material

,

ptfe graphite packing

Basic Infomation
Place of Origin: China
Brand Name: 3Arubber
Certification: RoHS/FCC/SGS
Model Number: 3A3006
Payment & Shipping Terms
Packaging Details: Packed in cartons
Delivery Time: 10 working days after recieved your payment
Payment Terms: L/C, T/T, Western Union,Paypal
Supply Ability: 10000000 rolls per month
Product Description

High Tensile Strength PTFE Expand Tape,PTFE Expand Tape for Industrial Seal with All Kinds of Color





CHEMICAL RESISTANCE:

Resistant to all media in the range of pH 0—14, except for molten or dissolved alkali metals and elemental fluorine at high temperatures and pressures





RESISTANCE TO AGEING:

The product is not susceptible to ageing in the permitted application range and can be stored indefinitely.





KEY FEATURES:

1 Made from 100% expanded PTFE(ePTFE)

2 High chemical and thermal resistance

3 Resistant to ageing

4 Physiologically safe

5 High strength





KEY BENEFITS:

1 Increased residual gasket stress

2 Greater blow-out resistance

3 High operating safety

4 Wide spectrum of applications

5 Reliably seals practically all media in the pH range 0—14

6 Highly conformable to the sealing surface

7 Straightforward installation



Specifications:

material pure PTFE dispersion resin
color white, FDA grade
adhesive backing adhesive or not
surface smooth
cross section rectangle, round
tensile strength 8Mpa
hardness 30-70shore A
density 0.7-1.0g/cm3
creep relaxation 70%
volatility 1.0%
PH 0-14
working pressure 1.6Mpa in gas, 6.4Mpa in liquid
working temperature -168°C ~ +280°C(maximum +315°C)
thickness 1.5-7.0mm
width 2.0-1500mm
length 1.5-25m
