High Tensile Strength FDA Grade PTFE Packing and Expand Tape for Industrial Seal with Wide Temperature Range

  • High Tensile Strength FDA Grade PTFE Packing and Expand Tape for Industrial Seal with Wide Temperature Range
  • High Tensile Strength FDA Grade PTFE Packing and Expand Tape for Industrial Seal with Wide Temperature Range
  • High Tensile Strength FDA Grade PTFE Packing and Expand Tape for Industrial Seal with Wide Temperature Range
  • High Tensile Strength FDA Grade PTFE Packing and Expand Tape for Industrial Seal with Wide Temperature Range
  • High Tensile Strength FDA Grade PTFE Packing and Expand Tape for Industrial Seal with Wide Temperature Range
  • High Tensile Strength FDA Grade PTFE Packing and Expand Tape for Industrial Seal with Wide Temperature Range
  • High Tensile Strength FDA Grade PTFE Packing and Expand Tape for Industrial Seal with Wide Temperature Range
Place of Origin China
Brand Name 3Arubber
Certification RoHS/FCC/SGS
Model Number 3A3006
Minimum Order Quantity 1000 rolls
Price negotiation
Packaging Details Packed in cartons
Delivery Time 10 working days after recieved your payment
Payment Terms L/C,T/T,Western Union,Paypal
Supply Ability 10000000 rolls per month

Contact me for free samples and coupons.

WhatsAPP:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Pure PTFE Expand Color White,yellow,red
Quality FDA Grade Density 0.15-0.5g/cm³
Working Temperature -150℃-+250℃ Thinkness 0.075-0.2mm
Width 3-100mm Length 6-50m
Highlight

ptfe packing material

,

ptfe graphite packing
Leave a Message
Product Description
High Tensile Strength PTFE Packing, PTFE Expand Tape for Industrial Seal
High Tensile Strength PTFE Expand Tape for Industrial Seal with All Kinds of Color
Chemical Resistance

Resistant to all media in the range of pH 0-14, except for molten or dissolved alkali metals and elemental fluorine at high temperatures and pressures.

Resistance to Ageing

The product is not susceptible to ageing in the permitted application range and can be stored indefinitely.

Key Features
  • Made from 100% expanded PTFE (ePTFE)
  • High chemical and thermal resistance
  • Resistant to ageing
  • Physiologically safe
  • High strength
Key Benefits
  • Increased residual gasket stress
  • Greater blow-out resistance
  • High operating safety
  • Wide spectrum of applications
  • Reliably seals practically all media in the pH range 0-14
  • Highly conformable to the sealing surface
  • Straightforward installation
Specifications
Material Pure PTFE dispersion resin
Color White, FDA grade
Adhesive Backing adhesive or not
Surface Smooth
Cross Section Rectangle, round
Tensile Strength 8Mpa
Hardness 30-70 shore A
Density 0.7-1.0g/cm³
Creep Relaxation 70%
Volatility 1.0%
PH Range 0-14
Working Pressure 1.6Mpa in gas, 6.4Mpa in liquid
Working Temperature -168°C to +280°C (maximum +315°C)
Thickness 1.5-7.0mm
Width 2.0-1500mm
Length 1.5-25m
High Tensile Strength FDA Grade PTFE Packing and Expand Tape for Industrial Seal with Wide Temperature Range 0 High Tensile Strength FDA Grade PTFE Packing and Expand Tape for Industrial Seal with Wide Temperature Range 1
