High Temperature Resistant Open Fiberglass PTFE Mesh Edge Reinforced Non Sticky
Place of Origin | China |
---|---|
Brand Name | 3A Rubber |
Certification | ROHS/FCC/SGS |
Model Number | 3A3008 |
Minimum Order Quantity | 1roll |
Price | negotiation |
Packaging Details | Packed in rolls |
Delivery Time | 10 working days after received your payment |
Payment Terms | T/T, L/C, Paypal, Western Union |
Supply Ability | 10000kgs per month |

Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xMaterial | Glassfiber Or Kevlar Coated PTFE | Color | Brown, Black, Blue |
---|---|---|---|
Joint | Bullnose Joint,spiral And Clapper | Temperature | -60 ~ +320°C |
Mesh | 0.5x1, 1x1, 2x2.5, 4x4, 6x6, 10x10mm | Width | Maximum 4.0m |
Highlight | ptfe conveyor belt,PTFE mesh conveyor belt |
high temperature resistant PTFE open fiberglass mesh , PTFE open fiberglass mesh
We use excellent fiberglass as the weaving material to plain knit or specially knit into superior fiberglass basic cloth, coat it with fine PTFE resin then make it into various PTFE PTFE high temperature resistance cloth in different thickness and width.We select fine glassfiber or Kevlar as basic weaving material, coated with excellent PTFE resin to make it into various PTFE open mesh conveyor belts.
PTFE Coated Fiberglass Open Mesh Conveyor Belt
1. High temperature resistance—It Can continuously work under-140 to 320°C,max resist high temperature up to 360°C.
2. Permeability—It can avoid wasting heat and improve drying efficiency for it’s permeability.
3. Chemical resistance—It can resist all most of chemical medicines.
4. Non Stick—It can easily remove all kinds of adhesives such as resin, paint and chemical
medicine, easy to clean.
Model | Mesh Size | Material | Thickness | Weight | Temp Resistance | Max Width | Tensile Strength |
1 | 1x1mm | fiberglass | 0.5mm | 370g/m² | -70~320°C | 4000mm | 310/290N/cm |
2 | 2x2mm | fiberglass | 0.7mm | 450g/m² | -70~320°C | 4000mm | 350/310N/cm |
3 | 4x4mm | fiberglass | 1.0mm | 400g/m² | -70~320°C | 4000mm | 390/320N/cm |
4 | 4x4mm | fiberglass | 1.0mm | 450g/m² | -70~320°C | 4000mm | 390/320N/cm |
5 | 4x4mm | fiberglass and kevlar | 1.2mm | 600g/m² | -70~320°C | 4000mm | 895/370N/cm |
6 | 4x4mm | fiberglass | 1.0mm | 500g/m² | -70~320°C | 4000mm | 395/370N/cm |
7 | 4x4mm | Kevlar | 1.0mm | 500g/m² | -70~320°C | 4000mm | 900/600N/cm |
8 | 4x4mm | fiberglass | 1.0mm | 550g/m² | -70~320°C | 4000mm | 395/370N/cm |
9 | 10x10mm | fiberglass | 1.2mm | 450g/m² | -70~320°C | 4000mm | 360/300N/cm |
10 | 0.5x1mm | fiberglass | 0.5mm | 420g/m² | -70~320°C | 4000mm | 310/290N/cm |
11 | 2x2.5mm | fiberglass | 0.9mm | 600g/m² | -70~320°C | 3000mm | 390/320N/cm |
1. Drying machine for non-woven textile, textile printing, silk-prnting and dyeing machine.
2. Shrinking machine for garment fabric, high-frequency and UV dryer.
3. Conveyer belt for hot-air dryer, various of food baking, quick-frozen machines.
4. Oiling machine for paper glazing and waxing, plant engineering.
5. Seperating sheet for hardboard production etc.
