hot sales Good size stability PTFE PTFE coated fiberglass fabric cloth for good quality
PTFE Coated Fiberglass Fabric is made of imported fiberglass as the wearing material to plain knit or specially knit into superior fiberglass basic cloth,coat it with fine PTFE resin then make it into various of PTFE high temperature resistance cloth in different thickness and width .
Features of PTFE fusing machine belt :
1. High temperature resistance -- it can continuously work under-140 to 360°C , max resist up to 380°C.
2. Non-adhesive -- it can easily remove all kinds of adhesives such as resin, paint and chemical medicine
3. Corrosion resistance -- it can resist acid, alkali, and various kinds of organic liquid corrosion.
4. Good size stability -- it has high tensile strength and good mechanical property.
5. Fireproofing and flame resistance.
6. Medicament resistant and no.n-poison.
Applications
1. Used as various of liners to resist high temperature, such as microwave liner, oven liner, BBQ mats, food drying or other liners.
2. Used as various of PTFE high temperature conveyor belts.
3. High insulation of electric: insulating belt of electric, septa, cushion, and gasket. High frequency plank coated with copper;
4. Heat resisting envelope, enswathing of heat insulation;
5. Binding of all sorts of petroleum and chemical pipeline to resist eroding, environmental sulfur separating of exhaust gas of electric factory
6. It could be made into static resisting fabric.
| Model | Color | Thickness | Max width | Weight | Tensile Strength | Temp Resistance |
| (mm) | (mm) | ( g/m² ) | (N/mm) | (°c) | ||
| 1008 | Brown | 0.08 | 1250 | 158±5 | 500/480/50 | -140~360 |
| 1008C | Black | 0.08 | 1250 | 160±5 | 620/460/50 | -140~360 |
| 1013A | Brown | 0.13 | 1250 | 290±5 | 910/880/50 | -140~360 |
| 1013B | Brown | 0.13 | 1250 | 215±5 | 1000/960/50 | -140~360 |
| 1013C | Brown | 0.13 | 1250 | 180±5 | 1100/900/50 | -140~360 |
| 1013G | White | 0.13 | 1250 | 290±5 | 910/880/50 | -140~360 |
| 1018G | White | 0.18 | 1250 | 310±5 | 1600/1600/50 | -140~360 |
| 1018C | Black | 0.18 | 1250 | 415±5 | 1500/1500/50 | -140~360 |
| 1025A | Brown | 0.25 | 1250 | 490±5 | 2800/2700/50 | -140~360 |
| 1025B | Brown | 0.25 | 1250 | 380±5 | 2200/2000/50 | -140~360 |
| 1025D | Brown | 0.25 | 1250 | 320±5 | 2500/2600/50 | -140~360 |
| 1025JK | Brown | 0.25 | 2250 | 490±5 | 2800/2700/50 | -140~360 |
| 1025JK2 | Brown | 0.25 | 2550 | 490±5 | 2800/270050 | -140~360 |
| 1029C | Black | 0.29 | 1200 | 400±5 | 2700/2500/50 | -140~360 |
| 1030C | Brown | 0.3 | 2600 | 520±5 | 2500/2400/50 | -140~360 |
| 1030JK | Brown | 0.3 | 2600 | 620±5 | 2800/2700/50 | -140~360 |
| 1035JK | Brown | 0.35 | 2500 | 670±5 | 2100/2000/50 | -140~360 |
| 1035JK1 | Brown | 0.35 | 2500 | 620±5 | 2200/2100/50 | -140~360 |
| 1035JK2 | Brown | 0.35 | 2500 | 560±5 | 2200/2100/50 | -140~360 |
| |
