nylon sheet , PA6 sheet , plastic sheet made with 100% virgin nylon PA6 material
nylon sheet is cast or extrude with 100% virgin nylon by molding of casting nylon PA6, PA66 sheet. Nylon is recognized as the most widely used and known engineering plastic in the current market. PA6 has the best performance, very tough, even at low temperatures, and high hardness in the surface, toughness, mechanical lower shock, and abrasion resistance. Combined with these characteristics and good insulation, and chemical properties, it has become common-level materials. Its widely used in a variety of mechanical structures and spare parts. Compared to PA6, PA66 own the higher hardness, rigidity, a good resistance to wear and heat deflection temperature. Apply to Bearings, gears, wheels, roller shaft, water pump impeller, fan blades, oil delivery pipe, oil storage pipe, rope, fishing nets and transformer coil.
Specifications:
| material | 100% virgin nylon PA6 |
| color | white, blue, black etc. |
| surface | smooth/smooth |
| tensile strength | 90Mpa |
| bending strength | 155Mpa |
| compression strength | 111.5Mpa |
| shear strength | 74-81Mpa |
| impact(no notch) | 520-624Kgf.cm/cm2 |
| hardness | R110-120M91-M88 |
| elongation | 10%-30% |
| density | 1.16g/cm3 |
| surface resistivity | 1x1013-1015ohm |
| volume resistivity | 1x1013-1015ohm.CM |
| vicat heat | 160-180kg.cm/cm2 |
| heat distortion temperature | +165°C |
standard size:
8-60mm x 1000mm x 2000mm
8-60mm x 1220mm x 2440mm
***when you enquiry, pls confirm the color, size and quantity***
