White And Black Color PTFE Sheet / 100 % Virgin PTFE Sheet Smooth Surface

Certification
China SANHE 3A RUBBER & PLASTIC CO., LTD. certification
China SANHE 3A RUBBER & PLASTIC CO., LTD. certification
I'm Online Chat Now

White And Black Color PTFE Sheet / 100 % Virgin PTFE Sheet Smooth Surface

White And Black Color PTFE Sheet / 100 % Virgin PTFE Sheet Smooth Surface
White And Black Color PTFE Sheet / 100 % Virgin PTFE Sheet Smooth Surface White And Black Color PTFE Sheet / 100 % Virgin PTFE Sheet Smooth Surface White And Black Color PTFE Sheet / 100 % Virgin PTFE Sheet Smooth Surface White And Black Color PTFE Sheet / 100 % Virgin PTFE Sheet Smooth Surface

Large Image :  White And Black Color PTFE Sheet / 100 % Virgin PTFE Sheet Smooth Surface

Product Details:
Place of Origin: China
Brand Name: 3A Rubber
Certification: ROHS/FCC/SGS
Model Number: 3A3001
Payment & Shipping Terms:
Minimum Order Quantity: 100kgs
Price: negotiation
Packaging Details: Packed in cartons
Delivery Time: 10 working days after received your payment
Payment Terms: L/C, T/T, Western Union, MoneyGram,Paypal
Supply Ability: 1000000pieces per month
Detailed Product Description
Material: Virgin PTFE Quality: Premium Grade
Color: White, Black Surface: Smooth/smooth
Tensile Strength: 20-30Mpa Hardness: 55+/-5shore D
Elongation At Break: 200%-320% Density: 2.1-2.3g/cm3
Break Down Voltage: 10KV/mm Temperature Resist: -180°C - +260°C
High Light:

ptfe coated fiberglass cloth

,

silicone coated fiberglass fabric

PTFE Sheet, PTFE Sheet, Plastic Sheet Made with 100 % Virgin PTFE Material, White and Black Color



Description: the PTFE sheet, PTFE sheet are made by moulded or skived with high quality polytetrafluoroethylene(PTFE) material. It is the best polymer material of chemical resistance in all knows plastic material. With excellent characteristics of corrosion resistance, weathering resistance, dielectric properties and lowest coefficient of fraction in all know solid materials, PTFE sheet can be widely used as corrosion-resistant linings, seals, gasket, guide, electric insulate parts and bearing pads for bridgeIt does not age.



Specifications:

material: virgin PTFE

quality: premium grade

color: white, black

surface: smooth/smooth

tensile strength: 20-30Mpa

hardness: 55+/-5shore D

elongation at break: 200%-320%

density: 2.1-2.3g/cm3

break down voltage: 10KV/mm

temperature resist: -180°C - +260°C

size of PTFE moulded sheet:

1.0-60mm x 150mm x 150mm

1.0-60mm x 250mm x 250mm

1.0-60mm x 300mm x 300mm

1.0-60mm x 450mm x 450mm

1.0-60mm x 600mm x 600mm

2.0-60mm x 800mm x 800mm

2.0-60mm x 1000mm x 1000mm

2.0-60mm x 1200mm x 1200mm

2.0-60mm x 1500mm x 1500mm

2.0-60mm x 1000mm x 2000mm



size for PTFE skived sheet:

0.3-6.0mm x 300mm x 10, 15, 20m

0.3-6.0mm x 600mm x 10, 15, 20m

0.3-6.0mm x 1000mm x 10, 15, 20m

0.3-6.0mm x 1200mm x 10, 15, 20m

0.3-6.0mm x 1500mm x 10, 15, 20m

0.3-6.0mm x 2000mm x 10, 15, 20m

packing in rolls and pallets

***when you enquiry, pls confirm the material, size and quantity***
