Premium Grade Virgin PTFE Coated Fiberglass Fabric with 20-30Mpa Tensile Strength and Corrosion-Resistant Properties
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ROHS/FCC/SGS |
| Model Number | 3A3001 |
| Minimum Order Quantity | 100kgs |
| Price | negotiation |
| Packaging Details | Packed in cartons |
| Delivery Time | 10 working days after received your payment |
| Payment Terms | L/C,T/T,Western Union,Paypal |
| Supply Ability | 1000000pieces per month |
Product Details
| Material | Virgin PTFE | Quality | Premium Grade |
|---|---|---|---|
| Color | White, Black | Surface | Smooth/smooth |
| Tensile Strength | 20-30Mpa | Hardness | 55+/-5shore D |
| Elongation At Break | 200%-320% | Density | 2.1-2.3g/cm3 |
| Break Down Voltage | 10KV/mm | Temperature Resist | -180°C - +260°C |
| Highlight | ptfe coated fiberglass cloth,silicone coated fiberglass fabric |
||
Product Description
20-30Mpa Premium Grade PTFE Coated Fiberglass Fabric - Corrosion Resistant
PTFE sheets are manufactured using high-quality polytetrafluoroethylene (PTFE) material through moulding or skiving processes. As the most chemically resistant polymer among all known plastic materials, PTFE sheets offer exceptional corrosion resistance, weathering resistance, dielectric properties, and the lowest coefficient of friction among all solid materials. These sheets are widely used as corrosion-resistant linings, seals, gaskets, guides, electrical insulating parts, and bearing pads for bridges. PTFE material does not age, ensuring long-term performance reliability.
Technical Specifications
| Material | Virgin PTFE |
| Quality Grade | Premium |
| Available Colors | White, Black |
| Surface Finish | Smooth/Smooth |
| Tensile Strength | 20-30 Mpa |
| Hardness | 55±5 Shore D |
| Elongation at Break | 200%-320% |
| Density | 2.1-2.3 g/cm³ |
| Breakdown Voltage | 10 KV/mm |
| Temperature Resistance | -180°C to +260°C |
PTFE Moulded Sheet Sizes
- 1.0-60mm * 150mm * 150mm
- 1.0-60mm * 250mm * 250mm
- 1.0-60mm * 300mm * 300mm
- 1.0-60mm * 450mm * 450mm
- 1.0-60mm * 600mm * 600mm
- 2.0-60mm * 800mm * 800mm
- 2.0-60mm * 1000mm * 1000mm
- 2.0-60mm * 1200mm * 1200mm
- 2.0-60mm * 1500mm * 1500mm
- 2.0-60mm * 1000mm * 2000mm
PTFE Skived Sheet Sizes
- 0.3-6.0mm * 300mm * 10, 15, 20m
- 0.3-6.0mm * 600mm * 10, 15, 20m
- 0.3-6.0mm * 1000mm * 10, 15, 20m
- 0.3-6.0mm * 1200mm * 10, 15, 20m
- 0.3-6.0mm * 1500mm * 10, 15, 20m
- 0.3-6.0mm * 2000mm * 10, 15, 20m
Packing: Rolls and Pallets
Important: When requesting a quote, please specify the material type, required dimensions, and quantity.
Important: When requesting a quote, please specify the material type, required dimensions, and quantity.
