Black Color PTFE Packing with Graphite for Industrial Seal, Density 1.4g/cm³ and Working Temperature -240℃ to +455℃

  • Black Color PTFE Packing with Graphite for Industrial Seal, Density 1.4g/cm³ and Working Temperature -240℃ to +455℃
  • Black Color PTFE Packing with Graphite for Industrial Seal, Density 1.4g/cm³ and Working Temperature -240℃ to +455℃
  • Black Color PTFE Packing with Graphite for Industrial Seal, Density 1.4g/cm³ and Working Temperature -240℃ to +455℃
  • Black Color PTFE Packing with Graphite for Industrial Seal, Density 1.4g/cm³ and Working Temperature -240℃ to +455℃
  • Black Color PTFE Packing with Graphite for Industrial Seal, Density 1.4g/cm³ and Working Temperature -240℃ to +455℃
  • Black Color PTFE Packing with Graphite for Industrial Seal, Density 1.4g/cm³ and Working Temperature -240℃ to +455℃
Place of Origin China
Brand Name 3Arubber
Certification RoHS/FCC/SGS
Model Number 3A3004
Minimum Order Quantity 10pieces
Price neogation
Packaging Details packed in cartons
Delivery Time 10 working days after recieved your payment
Payment Terms L/C,T/T,Western Union,Paypal
Supply Ability 10000kgs per month

Contact me for free samples and coupons.

WhatsAPP:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Pure Grafphite Color Black
Structure Lattic Braid Working Temperature -240℃-+455℃
PH Range 0-14 Size 3-50mm×3-50mm×5,10,15kgs
Highlight

silicone rubber gasket

,

silicone rubber seals
Leave a Message
Product Description
Black PTFE Packing Filled with Graphite for Industrial Seals
Black PTFE Packing filled with graphite is a high-performance industrial sealing solution with a density of 1.4g/cm³. This specialized yarn combines the exceptional properties of both PTFE and graphite to deliver superior sealing performance unmatched by conventional products.
Product Overview
Graphite PTFE Packing is an engineered sealing yarn that leverages the excellent sealing characteristics of both PTFE and graphite materials. This unique combination provides exceptional sealing properties that outperform alternative sealing solutions.
Typical Applications
  • Pumps, valves, reciprocating and rotating shafts
  • Mixers and agitators
  • Chemical pump applications (excluding molten alkali materials, fluoride, fuming nitric acid, and strong oxidizing agents)
  • Compatible with water, steam, petroleum derivatives, vegetable oil, and solvents
Technical Specifications
Material Composition
PTFE fiber, aramid fiber, graphite, lubricant
Structure
Lattice braid
Working Pressure
2-20 MPa
Working Speed
2-20 m/s
Temperature Range
-240°C to +288°C
Density
1.4 g/cm³
PH Range
0-14
Available Sizes
3-50mm x 3-50mm x 5, 10, 15 kgs
Available Variants
  • Pure PTFE Packing
  • PTFE Packing with Lubricant
  • PTFE Fiber Packing
  • PTFE Fiber Packing with Lubricant
  • PTFE Graphited Packing
  • PTFE Graphited Packing with Lubricant
  • PTFE + Aramid Fiber Packing
  • PTFE/Graphite + Aramid Fiber Packing
  • PTFE/Graphite + PTFE Packing
Technical Data Sheet
Material 100% Pure Graphite PTFE yarn
Temperature Range 150℃ up to +280℃
Rotating Pressure 20 bar
Reciprocating Pressure 100 bar
Static Pressure 150 bar
Shaft Speed 16 m/s
PH Range 0-14
Density 1.4-1.6 g/cm³
Black Color PTFE Packing with Graphite for Industrial Seal, Density 1.4g/cm³ and Working Temperature -240℃ to +455℃ 0 Black Color PTFE Packing with Graphite for Industrial Seal, Density 1.4g/cm³ and Working Temperature -240℃ to +455℃ 1
Important: When requesting a quote, please specify the material type, required dimensions, and quantity. Available impregnated with PTFE and packaged in spools and cartons.
