Food Grade PTFE Mesh Conveyor Belt with Chemical Resistance and Permeability for High Temperature Applications

Place of Origin China
Brand Name 3A Rubber
Certification ROHS/FCC/SGS
Model Number 3A3008
Minimum Order Quantity 1roll
Price negotiation
Packaging Details Packed in rolls
Delivery Time 10 working days after received your payment
Payment Terms T/T,L/C,Paypal,Western Union
Supply Ability 10000kgs per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Glassfiber Coated PTFE Color Brown, Black, Blue
Joint Bullnose Joint,spiral And Clapper Temperature -60 ~ +320°C
Mesh 0.5x1, 1x1, 2x2.5, 4x4, 6x6, 10x10mm Width Maximum 4.0m
Highlight

ptfe conveyor belt

,

PTFE mesh screen

Leave a Message
Product Description
Heat Resistance Food Grade PTFE Mesh 10 x 10mm, PTFE Mesh Conveyor Belt
High temperature resistant PTFE open fiberglass mesh, PTFE/PTFE mesh conveyor belt
Product Specifications
We manufacture PTFE coated fiberglass mesh fabric in various open mesh sizes to meet different industrial requirements.
Key Features
  • Heat resistance: Stable performance between -60°C to 260°C
  • Non-stick surface: Easily removes resins, oils, and other sticky substances
  • Mechanical strength: Low distortion and friction coefficient
Applications
Ideal for paper printing protection against oils and sticky substances. Widely used in print industry as conveyor belts.
For special requirements, please contact our research department.
PTFE Coated Fiberglass Open Mesh Conveyor Belt Advantages
  • Temperature resistance: Continuous operation from -140°C to 320°C (max 360°C)
  • Permeability: Reduces heat waste and improves drying efficiency
  • Chemical resistance: Withstands most chemical substances
  • Non-stick surface: Easy removal of adhesives and simple cleaning
Technical Specifications
Model Mesh Size Material Thickness Weight Temp Resistance Max Width Tensile Strength
1 1x1mm fiberglass 0.5mm 370g/m² -70~320°C 4000mm 310/290N/cm
2 2x2mm fiberglass 0.7mm 450g/m² -70~320°C 4000mm 350/310N/cm
3 4x4mm fiberglass 1.0mm 400g/m² -70~320°C 4000mm 390/320N/cm
4 4x4mm fiberglass 1.0mm 450g/m² -70~320°C 4000mm 390/320N/cm
5 4x4mm fiberglass and kevlar 1.2mm 600g/m² -70~320°C 4000mm 895/370N/cm
6 4x4mm fiberglass 1.0mm 500g/m² -70~320°C 4000mm 395/370N/cm
7 4x4mm Kevlar 1.0mm 500g/m² -70~320°C 4000mm 900/600N/cm
8 4x4mm fiberglass 1.0mm 550g/m² -70~320°C 4000mm 395/370N/cm
9 10x10mm fiberglass 1.2mm 450g/m² -70~320°C 4000mm 360/300N/cm
10 0.5x1mm fiberglass 0.5mm 420g/m² -70~320°C 4000mm 310/290N/cm
11 2x2.5mm fiberglass 0.9mm 600g/m² -70~320°C 3000mm 390/320N/cm
Common Applications
  • Drying machines for non-woven textiles, textile printing, silk-printing and dyeing machines
  • Shrinking machines for garment fabric, high-frequency and UV dryers
  • Conveyor belts for hot-air dryers, food baking equipment, and quick-freeze machines
  • Oiling machines for paper glazing, waxing, and plant engineering
  • Separating sheets for hardboard production
