dependable performance PTFE hose , PTFE tube , PTFE tubing for hot runner system
PTFE has the following outstanding features:
l Excellent electrical characteristics;
l Surface friction coefficient is low, strong anti-adhesive;
l Corrosion-resistant, not easy to aging;
l Low chemical reactivity, can be resistant to various chemicals;
l High temperature (-65--260) degrees Celsius.
Product Reference factor:
l Material: PTFE (ptfe)
l Application: Suitable for conveying hydraulic fluid, such as alcohol, fuel, lubricating oil, emulsion etc.
Specifications:
material: 100% virgin PTFE
quality: premium grade
color: white
surface: smooth
tensile strength: 20Mpa
hardness: 55+/-5shore D
elongation at break: 200%
density: 2.1-2.3g/cm3
break down voltage: 10KV/mm
temp resist: -180°C - +260°C
size for soft PTFE tube:
Ø2-35mm x Ø4-36mm x 10-50m length
| Hose Specifications(mm) | Inner diameter(mm) | Thickness(mm) |
| 2*4 | 2 | 1 |
| 3*5 | 3 | 1 |
| 3.5*5.5 | 3.5 | 1 |
| 4*6 | 4 | 1 |
| 5*7 | 5 | 1 |
| 6*8 | 6 | 1 |
| 8*10 | 8 | 1 |
| 9*11 | 9 | 1 |
| 9*12 | 9 | 1.5 |
| 10*12 | 10 | 1 |
| 12*14 | 12 | 1 |
| 13*15 | 13 | 1 |
| 14*16 | 14 | 1 |
| 15*18 | 15 | 1.5 |
| 16*18 | 16 | 1 |
| 22*22.4 | 20 | 1.2 |
| 20*33 | 20 | 1.5 |
| 20*24 | 20 | 2 |
| 22*25 | 22 | 1.5 |
| 25*28 | 25 | 1.5 |
| 32*36 | 32 | 2 |
