Virgin Nylon PA6 Plastic Rod with High Tensile Strength 90Mpa and Wide Range of Sizes for Industrial Applications
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ROHS/FCC/SGS |
| Model Number | 3A6004 |
| Minimum Order Quantity | 500kgs |
| Price | negotiation |
| Packaging Details | Packed in crates |
| Delivery Time | 10 working days after received your payment |
| Payment Terms | T/T,L/C,Paypal,Western Union |
| Supply Ability | 1000000kgs per month |
Product Details
| Material | Nylon PA6 Material | Color | Ivory, Blue, Black, Green |
|---|---|---|---|
| Tensile Strength | 90Mpa | Bending Strength | 155Mp |
| Density | 1.16g/cm3 | Size | Od10-400mm X 1000m |
| Highlight | nylon round bar,solid plastic rods |
||
Product Description
Moulded PA6 Nylon Plastic Rod For Wheel, Roller Shaft, Fan Blade 6mm x 1m
Product Overview
Nylon rod, PA6 rod, plastic rod made with 100% virgin nylon PA6 material.
Our nylon rod, PA6 rod is extruded and moulded with 100% virgin nylon PA6. Recognized as the most widely used engineering plastic in the current market, PA6 offers exceptional performance characteristics including high toughness even at low temperatures, superior surface hardness, mechanical shock resistance, and excellent abrasion resistance.
Combined with these mechanical properties and good insulation and chemical resistance, PA6 has become a common-grade material widely used in various mechanical structures and spare parts. Compared to PA6, PA66 offers higher hardness, rigidity, and better resistance to wear and heat deflection temperature.
Applications
Ideal for bearings, gears, wheels, roller shafts, water pump impellers, fan blades, oil delivery pipes, oil storage pipes, ropes, fishing nets, and transformer coils.
Technical Specifications
| Material | 100% virgin nylon PA6 |
|---|---|
| Production Method | Extrude, mould |
| Color | White, blue, black |
| Surface | Smooth |
| Tensile Strength | 49-82 Mpa |
| Density | 1.14 g/cm³ |
| Surface Resistivity | 1*10¹³-10¹⁵ ohm |
| Volume Resistivity | 1*10¹³-10¹⁵ ohm·cm |
| Vicat Heat | 160-180 kg·cm/cm² |
| Heat Distortion Temperature | +165°C |
Standard Sizes
Ø6mm x 1m
Ø7mm x 1m
Ø8mm x 1m
Ø10mm x 1m
Ø12mm x 1m
Ø15mm x 1m
Ø16mm x 1m
Ø18mm x 1m
Ø20mm x 1m
Ø22mm x 1m
Ø25mm x 1m
Ø28mm x 1m
Ø30mm x 1m
Ø32mm x 1m
Ø35mm x 1m
Ø40mm x 1m
Ø45mm x 1m
Ø50mm x 1m
Ø55mm x 1m
Ø60mm x 1m
Ø65mm x 1m
Ø70mm x 1m
Ø75mm x 1m
Ø80mm x 1m
Ø85mm x 1m
Ø90mm x 1m
Ø95mm x 1m
Ø100mm x 1m
Ø105mm x 1m
Ø110mm x 1m
Ø120mm x 1m
Ø125mm x 1m
Ø130mm x 1m
Ø140mm x 1m
Ø145mm x 1m
Ø150mm x 1m
Ø160mm x 1m
Ø170mm x 1m
Ø180mm x 1m
Ø190mm x 1m
Ø200mm x 1m
Ø210mm x 1m
Ø220mm x 1m
Ø230mm x 1m
Ø250mm x 1m
Ø260mm x 1m
Ø270mm x 1m
Ø280mm x 1m
Ø290mm x 1m
Ø300mm x 1m
Ø350mm x 1m
Ø400mm x 1m
Important: When making an enquiry, please confirm the color, size and quantity required.
