Premium Grade PTFE Rod - Corrosion Resistant, Temperature Resistant -180°C to +260°C, Smooth Surface Nylon Plastic Rod
| Place of Origin | China |
|---|---|
| Brand Name | 3A Rubber |
| Certification | ROHS/FCC/SGS |
| Model Number | 3A3002 |
| Minimum Order Quantity | 100kgs |
| Price | negotiation |
| Packaging Details | Packed in cartons |
| Delivery Time | 10 working days after received your payment |
| Payment Terms | T/T,L/C,Paypal,Western Union |
| Supply Ability | 1000000pieces per month |
Product Details
| Material | 100% Virgin PTFE Material | Color | White, Black |
|---|---|---|---|
| Tensile Strength | 20-30Mpa | Hardness | 50-60shore D |
| Elongation | 200-300% | Density | 2.1-2.3g/cm3 |
| Temperature Resist | -180°C - +260°C | Size | Od6-400mm X 300-1000mm |
| Highlight | nylon round bar,solid plastic rods |
||
Product Description
Premium Grade Smooth Surface Nylon Plastic Rod
Hardness: 55+/-5 Shore D
Product Overview
Premium grade PTFE rod, plastic rod available in white or black colors.
Manufactured using high-quality polytetrafluoroethylene (PTFE) material through moulded or extruded processes.
PTFE represents the best polymer material for chemical resistance among all known plastics.
Key Characteristics
Features excellent corrosion resistance, weathering resistance, dielectric properties, and the lowest coefficient
of friction among all known solid materials. Operates effectively across a wide temperature range from -180°C to +260°C.
The wax-like surface prevents materials from sticking. Available in various manufacturing methods based on diameter:
Ø4-9mm (paste extruded), Ø10-50mm (ram extruded), Ø50-300mm (moulded). Offers the best electrical properties of all plastics,
making it ideal for electrical insulation across various frequencies, corrosive medium seal liners, anti-sticking materials,
and lubrication applications.
Technical Specifications
| Material | 100% virgin PTFE |
| Quality | Premium grade |
| Color | White, Black |
| Surface | Smooth |
| Tensile Strength | 20Mpa |
| Hardness | 55+/-5 Shore D |
| Elongation at Break | 200% |
| Density | 2.1-2.3g/cm³ |
| Break Down Voltage | 10KV/mm |
| Temperature Resistance | -180°C to +260°C |
| Size Range | Ø6-400mm x 0.3-1m |
Standard Available Sizes
Ø6mm x 1m
Ø7mm x 1m
Ø8mm x 1m
Ø10mm x 1m
Ø12mm x 1m
Ø15mm x 1m
Ø16mm x 1m
Ø18mm x 1m
Ø20mm x 1m
Ø22mm x 1m
Ø25mm x 1m
Ø28mm x 1m
Ø30mm x 1m
Ø32mm x 1m
Ø35mm x 1m
Ø40mm x 1m
Ø45mm x 1m
Ø50mm x 1m
Ø55mm x 1m
Ø60mm x 1m
Ø65mm x 1m
Ø70mm x 1m
Ø75mm x 1m
Ø80mm x 1m
Ø85mm x 1m
Ø90mm x 1m
Ø95mm x 1m
Ø100mm x 1m
Ø105mm x 1m
Ø110mm x 1m
Ø120mm x 1m
Ø125mm x 1m
Ø130mm x 1m
Ø135mm x 1m
Ø140mm x 1m
Ø145mm x 1m
Ø150mm x 1m
Ø160mm x 1m
Ø170mm x 1m
Ø180mm x 1m
Ø190mm x 1m
Ø195mm x 1m
Ø200mm x 1m
Ø210mm x 1m
Ø220mm x 1m
Ø230mm x 1m
Ø250mm x 1m
Ø260mm x 0.3m
Ø270mm x 0.3m
Ø280mm x 0.3m
Ø290mm x 0.3m
Ø300mm x 0.3m
Ø350mm x 0.3m
Ø400mm x 0.3m
Additional Options
Black color available with 3% graphite or 10% carbon fill for enhanced properties.
Important: When making an inquiry, please confirm the color, size, and quantity requirements.
