White Color PTFE Gasket Tape One Side Adhesive For Industrial Seal

Certification
Good quality Silicone Rubber Sheet for sales
Good quality Silicone Rubber Sheet for sales
I'm Online Chat Now

White Color PTFE Gasket Tape One Side Adhesive For Industrial Seal

China White Color PTFE Gasket Tape One Side Adhesive For Industrial Seal supplier
White Color PTFE Gasket Tape One Side Adhesive For Industrial Seal supplier White Color PTFE Gasket Tape One Side Adhesive For Industrial Seal supplier White Color PTFE Gasket Tape One Side Adhesive For Industrial Seal supplier White Color PTFE Gasket Tape One Side Adhesive For Industrial Seal supplier White Color PTFE Gasket Tape One Side Adhesive For Industrial Seal supplier

Large Image :  White Color PTFE Gasket Tape One Side Adhesive For Industrial Seal

Product Details:

Place of Origin: China
Brand Name: 3Arubber
Certification: RoHS/FCC/SGS
Model Number: 3A3005

Payment & Shipping Terms:

Minimum Order Quantity: 10rolls
Price: neogation
Packaging Details: packed in cartons
Delivery Time: 10 working days after recieved your payment
Payment Terms: L/C, T/T, Western Union,Paypal
Supply Ability: 100000rolls per month
Contact Now
Detailed Product Description
Material: Pure PTFE Dispersion Resin Color: White
Quality: Food Grade Adhesive: One Side Adhesive Or Not
Cross: Rectangle Or Round Hardness: 30-70 Shore A
Working Temperature: -168℃-+280℃(maximum+135℃)

PTFE Expand Tape, PTFE Expand Tape for Industrial Seal with White Color



Description:

Made from import Dakin PTFE material, the expanded PTFE joint sealant tape with self-adhesivehas have very good flexibility, compression resilience, creep resistance, high/low temperature resistance, excellent corrosion resistance, non-aging property and self-lubricity.



Application Range:

For sealing various enameled linings, glass linings, plastic linings, rubber linings, graphite linings, and the flange faces of stainless/titanium steel towers, heat exchangers, reactors, etc.;

For sealing the flange faces of various pipelines and pipe fittings;

For sealing the flange faces of large-diameter equipment with bad surface machining accuracy, large uneven area, irregular shape and bolt fastening force difficult to be enough or unsuitable to be too big;

For sealing strongly corrosive media and fluid protected against any pollution.





Specifications:

material pure PTFE dispersion resin
color white, FDA grade
adhesive backing adhesive or not
surface smooth
cross section rectangle, round
tensile strength 8Mpa
hardness 30-70shore A
density 0.7-1.0g/cm3
creep relaxation 70%
volatility 1.0%
PH 0-14
working pressure 1.6Mpa in gas, 6.4Mpa in liquid
working temperature -168°C ~ +280°C(maximum +315°C)
thickness 1.5-7.0mm
width 2.0-1500mm


standard size for square type:




3mm x 1.5/2.0mm x 25/50m
5mm x 2.0/3.0mm x 25/50m
7mm x 2.0/3.0mm x 15/25m
10mm x 3.0/5.0/7.0mm x 15/25m
12mm x 3.0/5.0/7.0mm x 10/15/25m
15mm x 3.0/5.0/7.0mm x 10/15/25m
17mm x 3.0/5.0/7.0mm x 10/15/25m
20mm x 3.0/5.0/7.0mm x 10/15/25m
25mm x 3.0/5.0/7.0mm x 10/15/25m
30mm x 3.0/5.0mm x 5/10m
35mm x 3.0/5.0mm x 5/10m
40mm x 3.0/5.0mm x 5/10m
45mm x 3.0/5.0mm x 5/10m
50mm x 3.0/5.0mm x 5/10m




standard size for round type:
Ø2.4mm, Ø3.0mm, Ø4.0mm up to Ø25.0mm
standard size for PTFE expand sheet:
1.5mm x 1500mm x 1500mm
2.0mm x 1500mm x 1500mm
3.0mm x 1500mm x 1500mm
5.0mm x 1500mm x 1500mm
OEM sizes agreed
packing in round spool and cartons
***when you enquiry, pls confirm the size and quantity***Specifications:

White Color PTFE Gasket Tape One Side Adhesive For Industrial Seal
White Color PTFE Gasket Tape One Side Adhesive For Industrial SealWhite Color PTFE Gasket Tape One Side Adhesive For Industrial SealWhite Color PTFE Gasket Tape One Side Adhesive For Industrial Seal
