Good Insulation Cotton / Paper Phenolic Rod Smooth Length 1 - 3m

Certification
Good quality Silicone Rubber Sheet for sales
Good quality Silicone Rubber Sheet for sales
I'm Online Chat Now

Good Insulation Cotton / Paper Phenolic Rod Smooth Length 1 - 3m

China Good Insulation Cotton / Paper Phenolic Rod Smooth Length 1 - 3m supplier
Good Insulation Cotton / Paper Phenolic Rod Smooth Length 1 - 3m supplier Good Insulation Cotton / Paper Phenolic Rod Smooth Length 1 - 3m supplier Good Insulation Cotton / Paper Phenolic Rod Smooth Length 1 - 3m supplier Good Insulation Cotton / Paper Phenolic Rod Smooth Length 1 - 3m supplier Good Insulation Cotton / Paper Phenolic Rod Smooth Length 1 - 3m supplier

Large Image :  Good Insulation Cotton / Paper Phenolic Rod Smooth Length 1 - 3m

Product Details:

Place of Origin: China
Brand Name: 3Arubber
Certification: ISO9011
Model Number: 3A6013

Payment & Shipping Terms:

Minimum Order Quantity: 50kgs
Price: USD2.80/KG
Packaging Details: packed in creates
Delivery Time: 2-3 weeks after recieved your payment
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 1000000kgs per month
Contact Now
Detailed Product Description
Material: Phenolic+cotton Color: Brown,orange,black
Surface: Smooth Tensile Strength: 78Mpa
Compression Strength: 138Mpa Density: 1.25-1.40g/cm³
Rated Voltage: 10kv OD: 10-200mm
Length: 1-3m

Good Insulation Phenolic Cotton Rod,Phenolic Paper Rod for Electric Insulation Component



Specifications:

material 100% virgin silicone
quality industrial grade, food grade
color translucent, dark red, black, milk white, blue, grey etc.
surface smooth
tensile strength 7-9.8Mpa
hardness 30, 40, 50, 60, 70, 80+/-5shore A
elongation 350-700%
density 1.25g/cm3
tear strength 26-42N/mm
working temperature -60°C - +250°C
size build mould according to the buyer's drawing


***when you enquiry, pls confirm the color, hardness, quantity and drawing***



Features



Bakelite Rod is a hard, dense material made by applying heat and pressure to layers of paper or glass cloth impregnated with synthetic resin.These layers of laminations are usually of cellulose paper, cotton fabrics, synthetic yarn fabrics, glass fabrics or unwoven fabrics.When heat and pressure are applied to the layers, a chemical reaction (polymerization) transforms the layers into a high-pressure thermosetting industrial laminated plastic.



Applications
It is used for the insulating spare parts of the electrical appliances and transformers; textile machines. gears. fixed frame for bearing. low noise machine.
We are insulation material manufacturer.The main products are laminated sheets and rods for electrical insulation.



Good Insulation Cotton / Paper Phenolic Rod Smooth Length 1 - 3m

Good Insulation Cotton / Paper Phenolic Rod Smooth Length 1 - 3m
