Heat Resistant Silicone Foam Rubber Sheet 1-50mm Thick 180℃
| Place of Origin | China |
|---|---|
| Brand Name | 3Arubber |
| Certification | ROHS/FCC/SGS |
| Model Number | 3A1002 |
| Minimum Order Quantity | 200kgs |
| Price | USD3-15.00/kg |
| Packaging Details | packed in rolls and pallets |
| Delivery Time | 10-20 working day after recieveed your payment |
| Payment Terms | T/T,L/C,Paypal,Western Union,D/P,MoneyGram |
| Supply Ability | 100000kgs per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | Special For Ironing Table | Surface | Double Impression Fabric |
|---|---|---|---|
| Tensile Strength | 200psi | Hardness | 10-30 Shore A |
| Elongation | 100% | Density | 0.5-1.0g/cm³ |
| Thickness | 1-50mm | Width | 1-1.5m |
| Length | 1-10m | Cable | Custom |
| Oem | OEM Service Available | Agingresistance | Excellent |
| Heater Width | As Per The Buyer's Request | Products | Silicone Sponge Rubber Sheet |
| Elogation | ＞90% | Tensile Strenth | 1.4Mpa |
| Heat Resistant | 180℃ | Color | Transparent |
| Sample | Available | Warranty | Limited, Lifetime |
| Specific Gravity | 0.1-0.5g/cm3 | Uniform Heating | Maximum 220 Degree C |
| Highlight | silicone gasket sheet,flexible rubber sheet |
||
Product Description
Heat Resistant Silicone Foam Rubber Sheet / Silicone Sponge Rubber Sheet
High-performance silicone foam rubber sheets available in both closed cell and open cell configurations. Engineered for exceptional temperature resistance, durability, and insulation properties.
Key Features
- Excellent high temperature resistance (-60°C to +200°C continuous, up to +260°C intermittent)
- Superior aging, ozone, and weather resistance
- Outstanding heat insulation and acoustic properties
- Resistant to fuel oil and lubricants
- Odorless with high compressibility and low compression set
- Available in various colors, hardness levels, and surface finishes
Closed Cell Specifications
| Property | Specification |
|---|---|
| Cell Type | Closed cell |
| Material | Virgin silicone rubber |
| Available Colors | Dark red, black, white, beige, brown, grey, blue, etc. |
| Surface Finish | Double impression fabric |
| Tensile Strength | 100-200 PSI |
| Hardness (Shore A) | 10, 15, 20, 25, 30, 35, 40 ±5 |
| Elongation | 100% |
| Density | 0.5-1.0 g/cm³ |
| Working Temperature | -60°C to +220°C (momentary 260°C) |
| Thickness Range | 1-50 mm |
| Width Range | 0.1-1.5 m (maximum 1.5 m over 5 mm thickness) |
| Length Range | 0.1-10 m |
Standard Sizes (Closed Cell)
| 1-50 mm × 1.0 m × 10 m |
| 1-50 mm × 1.2 m × 10 m |
| 5-50 mm × 1.5 m × 10 m |
Open Cell Specifications
| Property | Specification |
|---|---|
| Cell Type | Open cell |
| Material | Virgin silicone rubber |
| Available Colors | Blue, red, yellow |
| Surface Finish | Cutting bubble |
| Tensile Strength | 100 PSI |
| Hardness (Shore A) | 15, 20, 25, 30, 35, 40, 45 ±5 |
| Elongation | 100% |
| Density | 0.15 ±0.02 g/cm³ |
| Working Temperature | -60°C to +220°C (momentary 260°C) |
| Thickness Options | 6, 8, 10, 15 mm |
| Width Options | 1.0, 1.5 m |
| Length Options | 5-10 m |
Standard Sizes (Open Cell)
| 6 mm × 1.0 m × 10 m |
| 6 mm × 1.5 m × 10 m |
| 8 mm × 1.0 m × 10 m |
| 8 mm × 1.5 m × 10 m |
| 10 mm × 1.0 m × 10 m |
| 10 mm × 1.5 m × 10 m |
| 15 mm × 1.0 m × 10 m |
| 15 mm × 1.5 m × 10 m |
Note: Custom OEM sizes available upon request. Backing adhesive options include general glue or 3M glue. Perforated silicone sponge rubber sheet available in 10 mm × 0.9 m × 1.8 m.
For inquiries: Please specify color, hardness, surface finish, dimensions, and quantity requirements.
